Tennant T7 80D (с управлением сидя) [39/113] Standard parts
![Tennant T7 80D (с управлением сидя) [39/113] Standard parts](/views2/1699464/page39/bg27.png)
STANDARD PARTS
2-29
T7+ 9013336 (08- 2014)
Fig. 14 - Disk Scrub Head Side Squeegee Group, Right
Ref. Part No. Description Qty.
1 1017910 ) Support Wldt, Sqge, Rh 1
2 1017832 Retainer, Sqge, Rh 1
3 1015989 Pin, Hitch, .312d X 1.62l 2
4 1017495 Sleeve, P/M, 0.496d 0.318b 1.375 Ss 1
5
1074201 Block, Guard, Yellow 1
6 222504 Screw, Hex, M8 X 1.25 X 55, Ss 1
7 08713 Nut, Hex, Lock, M8 X 1.25, Nl, Ss 1
8
86859 Squeegee Assy, Side [Linatex] 1
9 1010876 Link, Sqge 1
10 1017785 Link, Sqge 1
11 1011344 Spring, Tors 1
12 1011334 Spring, Tors 1
13 1011317 Retainer , Spring 2
14 1011717 Sleeve, P/M, 0.625d 0.318b 1.00 L 430ss 4
15 1011719 Washer, Flat, 0.33b 1.38d .075, Ss 8
16 49694 Screw, Hex, M8 X 1.25 X 50, Ss 2
17 222505 Screw, Hex, M8 X 1.25 X 45, Ss 2
18 08713 Nut, Hex, Lock, M8 X 1.25, Nl, Ss 2
