STANDARD PARTS
2‐37
T12 9009916 (8−2014)
356323
Fig. 18 − Vacuum Fan Group
Ref. Part No. Serial Number Description Qty.
o 1 1200149 (10000000−19999999 ) Fan, Vac, 6.6 Dia, Ametek 1
Y 1206774 (10000000−19999999 ) Brush Kit, Motor, Fan 1
2 1201267 (10000000−19999999 ) Assy, Seal, Mtg, Vacfan 1
3 49891 (10000000−19999999 ) Clamp, Hose, Wormdrive, 5.56−6.50d, .56w 1
4 08716 (10000000−19999999 ) Screw, Hex, M6 X 1.00 X 20, Ss 5
5 29570 (10000000−19999999 ) Washer, Flat, 0.28b 1.00d .06, Stl 5
6 1203848 (10000000−19999999 ) Muffler, Vacfan, 11.0 L 1
7 130773 (10000000−19999999 ) Tie, Cable, Nyl, 11.0l, .14w, 3.0 Max. D 1
8 1200369 (10000000−19999999 ) Insulation, Acstc, 0.5, 10.4 X 13.0 C−01
9 1200649 (10000000−19999999 ) Cover, Fan, Vacuum 1
10 140154 (10000000−19999999 ) Sleeve, P/M, 0.25b 0.38d 0.3l, Pl 2
11 15678 (10000000−19999999 ) Screw, Hex, M6 X 1.00 X 16, Ss 2
12 01684 (10000000−19999999 ) Washer, Flat, 0.27b 0.69d .05, Ss 2
13 1201875 (10000000−19999999 ) Hose, Vacuum, 1.75id X 68.6l, 2 Cuff 1
14 1067964 (10000000−19999999 ) Fastener, 25.0 [Hook & Loop] 1
15 1052126 (10000000−19999999 ) Inductor, 12.7Mmid [156 Imp At 25Mz] (Australia On-
ly)
1
16 16944 (10000000−19999999 ) Screw, hex, m4 X 0.70 X 10, Fmg 1
