Connection
Connection
Antenna input
• Connect an external DVB-T antenna
(cable) connector to the antenna RF IN.
The signal in the block cable antenna
can fail to contain DVB-T/T2 signal due to the
carrier frequency altered by the cable network
operator.
RF LOOP output
• Connect the output RF LOOP jack to TV's
antenna input using a special adapter (not
included) for supplying an analog TV signal.
HDMI-out
• If your TV has an HDMI video output,
connect it to an HDMI output of this unit using
a special HDMI cable (not included).
Coaxial output
• Connect the coaxial digital audio output to
the input of an amplifier to transmit the audio
signal to the amplifier using a special coaxial
cable (not included).
Stereo audio output
• Connect the left (white) and right (red)
terminal of the stereo audio output to the
corresponding audio inputs on your TV using
the supplied RCA-type cable.
Composite video (CVBS) output
• Connect the yellow video output to the
composite video input on your TV using
the included RCA cable for transmitting the
composite video signal.
Component video output
• Connect the component video output to
component video input on your TV using a
special cable (not supplied) to send component
video signal.
