Telefunken TF-LED24S1 [10/29] Usb operation
Operation
10
Operation
10
Timer setting
TIME
Sleep timer
Auto sleep
OSD timer
Move Menu OK Exit
• Sleep timer: select the period until
automatic switch-off of the unit (10 - 240 min).
• Auto sleep: select the period of time after
which the unit will automatically switch off if no
operation is done.
• OSD timer: select the period of time after
which the OSD will be hidden.
Option setting
OPTION
OSD language
Aspect ratio
Blue screen
Key lock
Reset
Software upgrade (USB)
Move Menu OK Exit
• OSD Language: select the language of
the OSD menu.
• TT Language: select teletext language.
• Aspect ratio: 4:3/16:9/Zoom1/Zoom2.
The set of available aspects can vary
depending on the current signal source.
• Blue screen: set on or off blue screen
activation when no signal.
• Key lock: select ON to lock all buttons on
the panel. Set OFF to unlock the buttons.
• Reset: reset the parameters to initial
factory settings.
• Software upgrade: this option is intended
for using by qualified technicians only.
USB operation
General playback information
• Insert a USB into the USB jack. Select
Media source and press ENTER button. The
screen will show a USB playback window, in
which you can select Music, Photo, Movie and
Text contents to play by pressing LEFT/RIGHT
cursor buttons and ENTER button.
• USB file systems supported: FAT16, FAT32,
NTFS. 2.0 USB version is supported; maximum
capacity 400 Gb. For correct and satisfactory
operation, licensed USB devices of famous
brands should be used with this unit. Avoid using
USB devices of unknown brands. Playback of
some file formates cannot be supported.
• This unit supports playback of video files
with AVI, MP4, TS/TRP, MKV, MOV, DAT,
VOB, RM/RMVB extension, with video codecs
WMV9, DIVX, H263, MPEG-4, MPEGII,
RV8/9/10 and audio codecs WMA, MP3, AAC,
MP 2, PCM. Video image resolution should not
be more than 576x720.
The above list of extensions and codecs
is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.
• Some AVI files cannot be played due to
their parameters and recording conditions.
Video files more than 2 Gb having AVI
extension can be played partially.
According to the USB 1.1/2.0 Standard,
usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.
Warning: usage of external USB drives
containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.
