LG W2040T [21/29] On screen display osd selection and adjustment

On Screen Display(OSD) Selection and Adjustment

Main menu Sub menu Description

NORMAL

The PhotoEffect function is disabled.

GAUSSIAN

BLUR

This menu changes the screen to be more

colorful and smoother.

SEPIA

This menu changes the screen to be

Sepia tone (brown color).

MONOCH

-ROME

This menu changed the screen to be

Gray tone (black-and-white Picture).

Exit : Exit

: Move

: Select another sub-menu

: Restart to select sub-menu
