FUNCTION

FUNCTION SWITCH

· Position to RADIO for:

-Radio reception

-Cassette recording from the radio

· Position to TAPE for:

-Cassette playback

-Recording from built-in Condenser Microphone

SOUND ADJUSTMENT

VOLUME

The level of sound reproduced by the loudspeaker or Stereo Headphones is adjusted by the VOLUME control.

NOTE:

During recording, adjusting the VOLUME control only affects the monitor sound and not the content of recording.

RADIO OPERATION

OPERATION

· Set Function switch to RADIO position thus the Power LED indicator should light up.

· Select your desired broadcasting band with Band switch.

· Rotate the Tuning control regulator to receive the desired broadcast.

· Adjust the level and quality of sound with Volume control switch.

· To turn off the radio, set the Function switch to TAPE position.

ANTENNA

· For FM reception, adjust the telescopic antenna appropriately to obtain the best reception on the band selected.

· The AM signals are picked up through the built-in ferrite antenna. The set should be placed to a position for the best reception.

FM AND FM STEREO RECEPTION

· Set Band switch FM position, programmer is received in mono mode.

NOTE: In particular when stereo signal is weak and much noise are received, it is preferable to receive the programmer in mono.

· Set FM MODE switch to FM STEREO position, programmer is received in stereo mode, thus FM STEREO LED should light up.
