Hyundai H-2201 [5/10] Maintenance and care
![Hyundai H-2201 [5/10] Maintenance and care](/views2/1008469/page5/bg5.png)
5
Recording from built-in condenser microphone
· Slide the FUNCTION switch to TAPE position.
· Insert a blank cassette into deck .
· Press the PLAY button and RECORD button on deck simultaneously to start recording.
NOTE:
· The built-in condenser microphone used in this unit have very high sensitivity. Therefore, it is not necessary to place the radio cassette recorder close to
the source of sound. Set the volume control to lower position during recording from built-in condenser microphone.
Maintenance and care
· Check your batteries regularly, old or discharged batteries should be replaced. If the unit is not going to be used for some time or is being run exclusively
on the alternative power, remove the batteries to avoid leakage and damage.
· Electronic products of this kind should never be subjected to moisture or extreme temperatures.
· If necessary, clean the unit with a piece of cloth dampened with water only (be sure the AC power cord is disconnected from the power supply).
· The heads and capstan are in constant contact with the moving tape. Use a small cotton bud with alcohol or special tape head cleaner to clean these parts.
Never touch the heads with anything metallic.
Erase protection
· To prevent accidental erasing of a cassette, simply break off the two plastic tabs located on the cassette tapes rear side.
· When a cassette with removed plastic tabs is inserted, the recording button cannot be pressed.
· If a cassette is to be erased and re-recorded at a later stage, simply cover the holes on the cassette where the tabs were
removed, with a piece of strong adhesive tape.
Specification
Power supply 220 V, 50 Hz
Power output 1 W/Channel
Net / Gross Weight 2.20 kg / 2.67 kg
Gift box dimension (L x W x H) 525 mm x 178 mm x 166 mm
Содержание
- H 2201 1
- Portable stereo radio double cassette recorde 1
- Ac operation 2
- Battery operation 2
- Description 2
- Important safeguards 2
- Power supply 2
- Antenna 3
- Cassette playback 3
- Cassette recorder operation 3
- Fm and fm stereo reception 3
- Radio operation 3
- Stereo headphone connecting 3
- Continuous playback 4
- Recording deck only 4
- Recording from radio 4
- Tape to tape recording 4
- Erase protection 5
- Maintenance and care 5
- Recording from built in condenser microphone 5
- Specification 5
