Alto TS 212 [7/27] Quick start

Quick Start

Items not list

d under Introduction > Box Contents are sold separately.

Example 1

Connect a dynamic microphone to the Input 1 using an

XLR or 1/4” (6.35 mm) TRS cable. Connect a guitar with

an active pickup to the Input 2 using a 1/4” (6.35 mm)

TS or TRS cable (see your guitar’s documentation for

cable requirements).

Note: When using the TS2 Series loudspeaker with a

guitar, we recommend using one with active pickups

rather than passive pickups. If you use a guitar with

passive pickups, connect it to an external preamp or

direct input (DI) box, and connect the line-level output to

the loudspeaker.

Also, use dynamic microphones with the TS2 Series

loudspeaker rather than condenser microphones. If you

use a microphone that requires +48V of phantom

power, connect it to an external phantom power supply

before connecting it to the loudspeaker.

Example 2

Connect the left and right output of your DJ mixer, controller, etc. to Input 1 of each

loudspeaker using XLR or 1/4” (6.35 mm) TRS cables.

Tip: To send the same mix to both TS2 Series loudspeakers, connect both channels of your

DJ mixer, controller, etc. to the Input 1 and Input 2 of one loudspeaker, and then connect that

loudspeaker’s Mix Out to the Input 1 of the other loudspeaker. Both TS2 Series loudspeakers

will then play identical summed mono mixes.
