LG L194WS-SF [6/27] To remove the stand base

Connecting the Display

To remove the Stand Base:

Hold the body of the Stand as it follows.

Type. A

3. Press inside the two long latches at the

same time with your strength as it follows.

5. The body of the Stand and the Stand Base are successfully separated.

4. Keep pressing the two latches and use the other

hand to hold the body of the Stand to push the

Stand Base in the arrow direction to remove.

1. Ensure there are two short and two long

latches at the bottom of the Stand Base.
