2
G Operating instruction
Thank you for choosing aHama product.
Take your time and read the following instructions and information completely.Please
keep these instructions in asafe place for futurereference. If you sell the device, please
pass these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic
hazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
• TV bracket
• Mounting column
• Bottom panel
• Installation kit (see contents, Fig. 1)
• These operating instructions
Note
Please check that the installation kit is complete beforeinstalling the TV Stand and
ensurethat none of the parts arefaulty or damaged.
3. Safety Notes
Warning
• Please contact aqualied specialist beforemounting the TV stand.
• Maintain the necessary safety clearance around the attached load (depending on
the model).
• After the TV stand has been mounted, check that it is suciently secureand safe
to use.
• Youshould repeat this check at regular intervals (at least every three months).
• In case of damage, remove the devices and do not continue to use the TV stand.
• Ensurethat the electrical cables arenot crushed or damaged during installation.
• Do not place loads on the TV stand that areheavier than the specied load
bearing capacity,and do not exceed the specied maximum screen size.
• Ensurethat the load on the TV stand is symmetrically balanced.
• Place the product only on at, non-slip surfaces that can bear the weight of the
product and the device attached to it.
• Check the general operational safety regularly,and make surethat the product and
the device attached to it arepositioned securely.
• Youshould repeat this check at regular intervals (at least every three months).
• In the event of damage to the product, remove the attached load and stop using
the product.
• Keep the packaging material out of the reach of children due to the risk of
suffocation.
• Dispose of packaging material immediately according to locally applicable
regulations.
• Do not modify the product in any way.Doing so voids the warranty.
• Do not attach any other objects to the product.
Note
Note that the feet of the product can cause pressuremarks on the surface on which
the product is positioned. This will depend on the weight load and the stability of the
surface wherethe product is located.
4. Intended use and specifications
• The product is used for mounting at panel displays for non-commercial, private
household use.
• The product is intended for indoor use only.
• Use the TV stand for the intended purpose only.
Screen size:
81.0 -165.0 cm (US: 32" -65")
Mounting holes: according to the VESA standarduntil: 600x400
Loading capacity of the wall
bracket:
40 kg
Pivoting range: up to 60° (depends on the device)
Dimensions of the bottom
panel:
42 x33cm
Height at the middle of the
TV plate :
55.4 cm
5. Installation requirements and installation
Note
• Only mount the TV stand with the help of asecond person! Get the support and
help you need.
• Ensurethat no electrical cables arecrushed or damaged during installation or
adjusting.
• Once you have mounted the product and the attached load, check that they are
suciently secureand safe to use.
• Observe the other warnings and safety instructions.
• Proceed step-for-step in accordance with the illustrated installation instructions
(Fig. 1ff.).
• Position the pre-assembled TV stand (g. 1to3)atthe desired point.
• First, xthe TV support arms to the VESA boreholes on the TV (g. 4) and then hang
the TV at the desired height (g. 5a).
• Mount and fasten the securing element (F2) to securethe bracket (g. 5a/detailed
view)
Note
• Given the multitude of terminal devices available on the market, we cannot
describe all possible mounting options here.
• Please ensurethat the bracket lays at and evenly on the back of the television.
• Use the enclosed spacer to even out any unevenness on the back of the television.
• Ensurethat all screws have the proper length and can be mounted until they are
hand-tight (see Fig. 4).
6. Setting and maintenance
Warning
• Only adjust the bracket with the help of asecond person. Get the support and
help you need.
• When doing so, ensurethat the product does not exceed its maximum permitted
carrying capacity and that no load exceeding the maximum permitted dimensions
is attached.
• Remove the TV from the bracket if you want to change the position of the TV
stand.
• Check that the bracket is secureand safe to use at regular intervals (at least every
three months). Only use water or standardhousehold cleaners for cleaning.
• If the rotate function is stiff,loosen the nut (A7) on the hinge slightly (g. 3, detailed
view a).
7. Warranty Disclaimer
Hama GmbH &CoKGassumes no liability and provides no warranty for damage
resulting from improper installation/mounting, improper use of the product or from
failuretoobserve the operating instructions and/or safety notes.
