GB Operating instruction Thank you for choosing a Hama product Take your time and read the following instructions and information completely Please keep Maximum load bearing capacity 25 kg Screen size 48 122 cm US 19 48 Depth 3 1 cm Angle 12 Wall mounting plate dimensions 26 2 x 17 5 cm Mounting holes according to the VESA standard until 200x200 these instructions in a safe place for future reference If you sell the device please pass these operating instructions on to the new owner 1 Explanation of Warning Symbols and Notes Warning This symbol is used to indicate safety instructions or to draw your attention to specific hazards and risks Note This symbol is used to indicate additional information or important notes 5 Installation requirements and installation 2 Package Contents Note TV wall bracket Only mount the TV wall bracket with the help of a second person Get the support TV support arms 2x and help you need Installation kit see contents Fig 1 These operating instructions Different end devices have different options for connecting cables and other devices 0 Note Please check that the installation kit is complete before installing the Before installation ensure that the necessary connections will still be accessible after installation The same mounting kit is included with all of our TV wall brackets Depending on bracket and ensure that none of the parts are faulty or damaged the product and mounting type you may not need to use the entire mounting kit Un needed screws and other small parts may be left over even if the wall bracket 3 Safety Notes Warning A is properly mounted Keep these leftover parts with the operating instructions in a safe place just in case you might need them later on e g should you move sell the product mount the wall bracket in a different location buy a new TV etc Given the multitude of terminal devices and wall structures available on the market A the supplied mounting kit is unable to cover every option It occa sio n a lly ha p pe ns that th e screws fo r attach i n g th e te rm i na I dev i ce to t h e wa II bracket are too long Please note that the supplied wall plugs are for use with concrete brick and solid brick walls only Read the operating instructions for your terminal device before attempting to mount it The instructions provide information about the type and measurements of suitable fastening materials If the supplied mounting kit does not contain suitable fastening materials for mounting the terminal device purchase these from a specialised dealer If the wall on which the bracket is to be mounted is made of different material types Warning This product is suitable for wall mounting only Before installing the bracket ensure that the wall on which the television is to be mounted is suitable for the weight and make sure that no electrical wires water gas or other lines are located at the installation location Please note that the provided wall anchors are only approved for concrete and solid brick walls Observe the other warnings and safety instructions Proceed step for step in accordance with the illustrated installation instructions Fig 1 ff and construction types to those specified purchase suitable mounting materials from a specialised dealer Never apply force during mounting This can damage your end device or wall bracket If in doubt have this product mounted by a qualified technician do not attempt to mount it yourself Given the multitude of terminal devices available on the market we cannot describe all possible mounting options here Please ensure that the bracket lays flat and evenly on the back of the television Use the enclosed spacer to even out any unevenness on the back of the television Do not mount the product above locations where persons might linger Once you have mounted the product and the attached load check that they are sufficiently secure and safe to use Ensure that all screws have the proper length and can be mounted until they are hand tight see Fig 2 You should repeat this check at regular intervals at least every three months 6 Setting and maintenance When doing so ensure that the product does not exceed its maximum permitted carrying capacity and that no load exceeding the maximum permitted dimensions is Note attached Only adjust the TV wall bracket with the help of a second person Get the support and Make sure that the product is loaded symmetrically help you need Maintain the necessary safety clearance around the attached load depending on the model In the event of damage to the product remove the attached load and stop using the product To adjust the inclination loosen the side mounting screws slightly set the desired angle and retighten the screws securely Check that the bracket is secure and safe to use at regular intervals at least every three months Only use water or standard household cleaners for cleaning 4 Intended use and specifications To secure insert the carrying arms into the wall plate and tighten both screws The bracket is used for wall mounting flat panel displays for non commercial private household use 7 Warranty Disclaimer The bracket is only intended for use within buildings Hama GmbH Co KG assumes no liability and provides no warranty for damage resulting Use the bracket only for the intended purpose from improper installation mounting improper use of the product or from failure to observe the operating instructions and or safety notes 2 R1118159man_cs_de_en_pl_ru_sk indd 2 09 08 21 16 37
