LG L1953TR-BF.AEUSQPN [21/26] Display
![LG L1953TR-BF.AEUSQPN [21/26] Display](/views2/1084978/page21/bg15.png)
A20
Specifications 19 inch
NOTE
Information in this document is subject to change without notice.
Display
Sync Input
Video Input
Resolution
Plug&Play
Power
Consumption
Dimensions
&Weight
Tilt Range
Power Input
Environmental
Conditions
Stand Base
Power cord
19 inches (48.19 cm) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
19 inches viewable
0.294 mm pixel pitch
Horizontal Freq. Analog : 30 - 83 kHz (Automatic)
Digital : 30 - 71 kHz (Automatic)
Vertical Freq. 56 - 75 Hz (Automatic)
Input Form Separate TTL, Positive/Negative
SOG (Sync On Green)
Digital
Signal Input 15 pin D-Sub Connector
DVI - D connector (Digital)
Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital
Max Analog : VESA 1280 x 1024 @75 Hz
Digital : VESA 1280 x 1024 @60 Hz
Recommend VESA 1280 x 1024 @60 Hz
DDC 2B
On Mode
:33 W(Typ.)
Sleep Mode≤1 W
Off Mode ≤ 1 W
With Stand Without Stand
Width 40.20 cm / 15.83 inches 40.20 cm / 15.83 inches
Height 40.75 cm / 16.04 inches 33.30 cm / 13.11 inches
Depth 18.00 cm / 7.08 inches 5.80 cm / 2.28 inches
Net 4.4 kg (9.70 lbs)
Tilt -5˚~20˚
AC 100-240V~ 50/60Hz 0.8A
Operating Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Attached( ), Detached ( O )
Wall-outlet type or PC-outlet type
