7
Cordless Lawn mower EN
GENERAL SAFETY WARNINGS
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire
and/or serious injury.
Carefully read the instructions for the safe
operation of the machine.
Save all warnings and instructions for future
reference.
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they
do not play with the appliance.
- The appliance is only to be used with the power
supply unit provided with the appliance.
Training
a) read the instructions carefully. Be familiar with the
controls and the proper use of the equipment;
b) never allow children or people unfamiliar with
these instructions to use the lawnmower. Local
regulations can restrict the age of the operator;
c) never mow while people, especially children, or pets
are nearby;
d) keep in mind that the operator or user is responsible
for accidents or hazards occurring to other people
or their property
Preparation
a) While mowing, always wear substantial footwear
and long trousers. Do not operate the equipment
when barefoot or wearing open sandals;
b) thoroughly inspect the area where the equipment
is to be used and remove all objects which can be
thrown by the machine;
c) Before using, always visually inspect to see that
the blades, blade bolts and cutter assembly are not
worn or damaged. Replace worn or damaged blades
and bolts in sets to preserve balance;
d) On multi-bladed machines, take care as rotating one
blade can cause other blades to rotate.
Operation
a) mow only in daylight or in good artificial light;
b) avoid operating the equipment in wet grass, where
feasible;
c) always be sure of your footing on slopes;
d) walk, never run;
e) for wheeled rotary machines, mow across the face
of slopes, never up and down;
f) exercise extreme caution when changing direction
on slopes;
g) do not mow excessively steep slopes;
h) use extreme caution when reversing or pulling the
lawn mower towards you;
i) stop the blade(s) if the lawn mower has to be tilted
for transportation when crossing surfaces other
than grass, and when transporting the lawn mower
to and from the area to be mowed;
j) never operate the lawn mower with defective
guards, or without safety devices, for example
deflectors and/or grass catchers, in place;
k) switch on the motor carefully according to
instructions and with feet well away from the
blade(s);
l) do not tilt the lawn mower when switching on the
motor, except if the lawnmower has to be tilted
for starting In this case, do not tilt it more than
absolutely necessary and lift only the part which is
away from the operator;
m) do not put hands or feet near or under rotating
parts. Keep clear of the discharge opening at all
times;
n) never pick up or carry a lawn mower while the
motor is running;
o) not to touch the blades before the disabling device
has been removed and the blades have come to a
complete stop;
p) to remove the disabling device
– whenever you leave the machine;
– before clearing a blockage;
– before checking, cleaning or working on the
machine;
– after striking a foreign object, Inspect the lawn
mower for damage and make repairs as necessary;
– if the lawnmower start to vibrate abnormally(check
immediately);
Maintenance and storage
a) keep all nuts, bolts and screws tight to be sure the
equipment is in safe working condition;
b) check the grass catcher frequently for wear or
deterioration;
c) replace worn or damaged parts for safety;
d) ensure that only replacrment cutting means of the
right type are used;
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells or
battery pack.
b) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box or
drawer where they may short-circuit each
other or be short-circuited by conductive
materials. When battery pack is not in use, keep
it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery terminals
together may cause burns or a fire.
c) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical
shock.
e) In the event of battery leaking, do not allow
the liquid to come into contact with the skin
