LG L222WS-BN [20/23] Specifications
![LG L222WS-SN [20/23] Specifications](/views2/1085292/page20/bg14.png)
A19
Specifications
NOTE
Information in this document is subject to change without notice.
Display
Sync Input
Video Input
Resolution
Plug&Play
Power
Consumption
Dimensions
&Weight
Tilt Range
Swivel Range
Power Input
Environmental
Conditions
Stand Base
Signal cable
Power cord
21.6 inches (54.864 cm) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
21.6 inches viewable
0.27675*0.27675 mm pixel pitch
Horizontal Freq. 30 - 83 kHz (Automatic)
Vertical Freq. 56 - 75 Hz (Automatic)
Input Form Separate TTL, Positive/Negative
SOG (Sync On Green)
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Max VESA 1680 x 1050 @ 60 Hz
Recommend VESA 1680 x 1050 @ 60 Hz
DDC 2B
On Mode
: 45W(Typ.)
Sleep Mode ≤ 1 W
Off Mode ≤ 1 W
With Stand Without Stand
Width 50.17 cm / 19.75 inches 50.17 cm / 19.75 inches
Height 42.19 cm / 16.61 inches 33.74 cm / 13.28 inches
Depth 23.39 cm / 9.21 inches 5.95 cm / 2.34 inches
Net 5.65 kg (12.56 lbs)
Tilt -5˚~20˚
Swivel 355˚
AC 100-240V~ 50/60Hz 1.0A
Operating Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Attached ( ), Detached ( O )
Attached ( ), Detached ( O )
Wall-outlet type or PC-outlet type
