Sharp AQUOS 32BC4E [16/28] Attaching the stand

What is included in the box

Supply of this TV includes following parts:

• 1x TV • 1x TV stand installation packet

• 1x Remote control • 1x User guide

• 2x AAA batteries

Attaching the Stand

Please follow the instructions on last page of this user manual.

Wall mounting the TV

1. Remove the four screws that are supplied in the wall mounting holes.

2. The wall mount can now be easily attached to the mounting holes on

the rear of the TV.

3. Install the wall mounting bracket to the television as advised by the

bracket manufacturer.

Getting started - initial set up

1. Using the RF cable, connect the TV to the TV Aerial wall socket.

2. For connecting to the Internet with a wired connection connect a

Cat 5/Ethernet cable (not included) from the TV to your broadband

modem/router.

3. Connect the power cable to the Electrical outlet.

4. Insert the batteries supplied into the Remote control.

5. Then press Standby button to power on TV.

6. You will be now welcomed with the First Time Installation screen.

If it does not appear, on the remote control, please press [MENU] then

8-8-8-8 and the menu will appear.

If you wish to make changes to any of the default settings, use the

scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press [EXIT]

button.

7. Please set desired settings in First Time Installation screen.

Welcome screen - press OK on the remote control to continue to the

next screen.

STEP 1 - Set the TV Menu language.

Data collection notice - here you can read information about data

collection. You can view more detailed information and personalize

data collection settings in "View additional details" screen.

STEP 2 - Set your country

STEP 3 - Select the location of TV. For home use, please select "Home

Mode". For shop demonstration mode, set "Store Mode".

STEP 4 - Set type of network connection. If you wish to skip this step

and connect TV to network later, please choose option "It's OK, I'll do

it later".

Set up Net ix - By choosing "Start Net ix" option you will be able to

wish to set up Net ix now, please select "Skip".

STEP 5 - Choose input source which you want to use. If you have

connected RF cable directly to TV, choose "Digital TV". If you have

satellite directly connected to your TV, choose "Satellite". In case

you are using set-top-box, please pick correct input to which it is

connected.

8. If you selected in last step "Digital TV" or "Satellite", you will be asked if

you want to tune channels. If you choose “No”, you can tune channels

later from SETTINGS/CHANNEL menu. If you choose “Yes”, tuning

menu will appear.

Digital TV tuning: In "DVB Antenna", please choose which type of

signal you have. Air (DVB-T) or Cable (DVB-C). Then enter "Auto Scan"

and set your desired settings. Then choose "Auto Tuning" to start

tuning of channels.

Satellite (DVB-S2) tuning: Enter "Satellite Setup" and in "Antenna

Setup" select satellite which you wish to tune. Then return to previous

menu by pressing BACK button on your remote control and choose

"Auto tuning" to start tuning of channels.

NOTE: To shorten tuning time of satellite channels, some countries

have preinstalled channel list for most popular satellite in that region.

If this is the case for your selected country, you will be asked if you

wish to load preinstalled channel list. If you choose “Yes”, satellite

channel list will be imported to your TV within few seconds.

TIP: If you are missing channels, the reason for this is likely to be signal

strength, you should consider connecting signal booster and re-tuning the TV.

Remote control

1. STANDBY – Switch on TV when in standby or vice versa.

MUTE – Mute the sound or vice versa.

3. 0 – 9 – to select aTV channel directly.

4. TV GUIDE – Opens the 7 Day TV Guide (Digital mode).

– To return to the previous channel viewed.

6. PICTURE – Scrolls through picture mode options.

7. VOL ▲/▼ – To increase / decrease the sound level.

8. CH ▲/▼ – To increase or decrease the channel being watched.

9. SOUND – Scrolls through sound mode options.

10. SOURCE – To display the input/source menu.

11. MENU – To display OSD menu.

12. EXIT – To exit all menus.

13. (▲/▼/◄/►/ OK) – Allows you to navigate the on-screen menus and

adjust the system settings to your preference.

14. BACK – Back to previous menu.

15. FAV – To display favourites menu.

16. INFO – Press once for now/next channel information. Press twice for

programme information about current programme.

17. TEXT – Teletext mode - To enter Teletext

18. SUBTITLE – To switch the dialogue at the bottom of the screen (on/

o ).

19. TV – Switch to digital TV source.

20. YouTube – Displays YouTube application

21. NETFLIX – Displays NETFLIX application

22. NET+ – Displays AQUOS NET+ menu.

23. Rec

– PVR Record

24.

– To restart the current chapter

25.

– To advance forward to the next chapter

26.

– To stop the playback

27. Rec List

– Opens the list of recordings.

28.

– To play in fast rewind mode.

29.

– To play in fast forward mode.

30.

– To play/pause

31. COLOUR BUTTONS

– Additional teletext and OSD functions

- available only with PVR function

TV Control Stick

The TV control stick is located on the back of the TV. You can use it instead

of remote control to control most of the functions of your TV.

While TV is in standby mode:

• short press of control stick - Power On

While watching TV:

• RIGHT/LEFT – volume up/volume down

• UP/DOWN – changes channel up/down

• short press – Displays Menu
