![LG 21FE4RGE-TY [17/24] Sound adjustment option](/img/pdf.png)
LG 21FE4RGE-TY [17/24] Sound adjustment option
![LG 21FE4RGE-TY [17/24] Sound adjustment option](/views2/1085595/page17/bg11.png)
17
Balance adjustment
1. Press the MENU button to select the Sound menu.
2. Press the button and then button to select Balance.
3. Make desired adjustment with the on the Balance pull-down
menu.
4. Press the TV/AV button to return to normal TV viewing.
Sound output selection
In AV mode, you can select output sound for the left and right
loudspeakers.
Repeatedly press the I/II/ button to select the sound output.
L+R : Audio signal from audio L input is sent to left loud-
speaker and audio signal from audio R input is sent
to right loudspeaker.
L+L : Audio signal from audio L input is sent to left and
right loudspeakers.
R+R : Audio signal from audio R input is sent to left and
right loudspeakers.
TURBO SOUND (option)
When this function is On, sound will be more emphasized and
amplified sound than normal sound. You can enjoy the TURBO
SOUND so much better than normal Sound.
Repeatedly press the TURBO SOUND button to switch On or Off.
CBC (Calibrated Bass Control) (Option)
By using this function you can adjust the desired bass level.
You can adjust balance.
(Turbo Sound Effect Off) (Turbo Sound Effect On)
TURBO
EQ/*
POWER
MUTE
1
2
3
4
5
6
7
8
9
0
CBC
PSM
PR
Q-VIEW
LIST
SSM
SLEEP
MENU
PR
OK
VOL
VOL
TV/AV
EYE/*
ARC
I/II
SOUND
TURBO
Sound adjustment (option)
SOUND MENU
BALANCE
EQUALIZER
