LG E2422PY-BN [26/28] Installing the wall mount plate
![LG E2422PY-BN [26/28] Installing the wall mount plate](/views2/1085912/page26/bg1a.png)
25
Installing the Wall mount plate
This monitor satisfies the specifications of the Wall mount plate or
the interchange device.
1
.
After moving the product to face
downward, make sure to place it on a
soft cloth or a cushion to avoid surface
damage.
2.
Separate the head and the stand with
the use of a screwdriver.
