VACUUM CLEANER MW-3244

The vacuum cleaner is intended for room dry cleaning.

DESCRIPTION

1. Universal brush with the “FLOOR/CARPET” switch

2. “FLOOR/CARPET” switch

3. Extension pipe (2 sections)

4. Manual suction power control

5. Flexible hose handle

6. Flexible hose

7. Dust bin

8. Flexible hose ending

9. Air inlet

10. Filter block lid

11. Vacuum cleaner carrying handle

12. Power cord winding button

13. Dust bin release button

14. Horizontal brush storage

15. ON/OFF button

16. Grid with installed outlet air filter

17. Dust bin lid lock

18. HEPA filter

19. Mesh filter of the HEPA filter

20. Combined attachment

21. Furniture brush attachment

22. Attachment holder

SAFETY MEASURES

Read this instruction manual carefully before using the unit

and keep it for the whole operation period.

Use the unit for its intended purpose only, as specified

in this manual. Mishandling of the unit may lead to its

breakage and cause harm to the user or damage to his/

her property.

To avoid the risk of fire, electric shock and to prevent

injury, observe the following safety measures.

• Before connecting the unit to the mains, make sure

that the voltage specified on the unit corresponds to

your home mains voltage.

• To avoid fire, do not use adapters for connecting the

unit to the mains.

• Do not leave the plugged in vacuum cleaner unattend-

ed. Always unplug the vacuum cleaner from the mains

if it is not being used, before changing attachments or

before unit maintenance.

• To prevent the risk of electric shock, do not use the

vacuum cleaner outdoors, do not use it for collect-

ing water or any other liquids (do not use the vacuum

cleaner on wet surfaces).

• Carry the vacuum cleaner holding it by the carrying

handle only.

• Do not use the power cord for carrying the vacuum

cleaner, do not close the door if the power cord runs

through the doorway, do not let the power cord come

in contact with sharp corners or edges of furniture, and

with hot surfaces. Do not run over the power cord with

the vacuum cleaner while room cleaning as this can

damage it. Always first switch the vacuum cleaner off

with the ON/OFF button and only after that take the

power plug out of the mains socket.

• When unplugging the unit, pull the plug but not cord.

• Do not touch the plug or the body of the vacuum clean-

er with wet hands.

• Hold the winding cord with hand to avoid the plug hit-

ting against the floor.

• Do not cover the unit outlet with any objects.

• Do not switch the unit on if any of its openings are

blocked.

• Keep hair, free hanging clothes, fingers and other parts

of your body away from the vacuum cleaner air inlets.

• Be especially cautious while cleaning the stair land-

ings.

• Do not use the vacuum cleaner for collecting such

highly inflammable liquids as gasoline and solvents,

do not use the vacuum cleaner in places where such

liquids are stored.

• Do not use the vacuum cleaner for collecting water and

other liquids, burning or smoking cigarettes, matches,

cinders as well as fine dust, for example, of plaster,

concrete, flour or ashes.

• Do not use the vacuum cleaner if:

– the dustbag is not installed or installed improperly;

– the inlet and outlet filters are not installed.

• Do not immerse the unit body into water or other

liquids.

• Use only the accessories and attachments supplied.

• Clean the vacuum cleaner regularly.

• Keep the vacuum cleaner in a dry cool place.

• Do not use the vacuum cleaner to clean pets.

• Close supervision is necessary when children or dis-

abled persons are near the operating unit.

• This unit is not intended for usage by children. During

the unit operation and breaks between operation

cycles, place the unit out of reach of children.

• The unit is not intended to be used by people with

physical, sensory or mental disabilities (including chil-

dren) or by persons lacking experience or knowledge

if they are not under supervision of a person who is

responsible for their safety or if they are not instructed

by this person on the usage of the unit.

• Do not leave children unattended to avoid them using

the unit as a toy.

• For children safety reasons do not leave polyethylene

bags, used as packaging, unattended.

Attention! Do not allow children to play with polyethylene

bags or packaging film. Danger of suffocation!

• Regularly check the power plug and power cord integ-

rity for damages.

• Never use the unit if the power cord or the power plug

is damaged, if the unit works improperly or after it

was dropped.

• Do not attempt to repair the unit. Do not disassemble

the unit by yourself, if any malfunction is detected or

after it was dropped, unplug the unit and apply to any

authorized service center from the contact address

list given in the warranty certificate and on the website

www.maxwell-products.ru.

• Transport the unit in the original package only.

• Keep the unit out of reach of children and disabled

persons.

THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.

ITS COMMERCIAL USAGE AND USAGE IN PRODUCTION

AREAS AND WORK SPACES IS PROHIBITED.

BEFORE THE FIRST USE

After unit transportation or storage at low tempera-

ture keep it for at least three hours at room tempera-

ture before switching on.

– Unpack the unit, remove any stickers and package mate-

rials that can prevent the vacuum cleaner operation.

– Check the unit for damages; do not use it in case of

damages.

– Before switching the unit on, make sure that your home

mains voltage corresponds to the unit operating voltage.

ASSEMBLING THE VACUUM CLEANER

Attaching and removing the flexible hose

• Insert the flexible hose ending (8) into the air inlet (9)

and turn it clockwise until locking.

• Insert the hose ending applying little effort.

• If you need to remove the flexible hose, turn the flexible

hose ending (8) counterclockwise and detach.

Attaching the extension pipe and attachments

• Connect 2 sections of the extension pipe (3) and con-

nect the pipe to the flexible hose handle (5).

• Choose the necessary attachment – universal floor/

carpet brush (1), furniture brush (21) or combined

attachment (20) – and attach it to the extension pipe (3).

• If necessary, you can attach the attachments (20, 21)

directly to the flexible hose handle (5).

• During the unit operation hold it by the flexible hose

handle (5).

USING THE BRUSH ATTACHMENTS

Universal brush with

the “FLOOR/CARPET” switch (1)

Set the switch (2) on the brush (1) to the required position

(depending on the type of the surface being cleaned).

Combined attachment (20)

The furniture brush attachment is intended not only for

cleaning radiators, crevices, corners or space between

cushions, but for collecting dust from furniture surface

as well, the pile on the brush (20) prevents damage of

polished furniture surface. During the operation set the

brush to the required position.

Attachment (21)

Use the attachment (21) to clean the furniture upholstery.

Dust bin (7)

The dust bin is equipped with the cyclonic filter which

eliminates garbage and dust from the air, and the outlet

air foam filter and the HEPA filter (18) retain the finest dust

particles. The mesh filter (19) protects the HEPA filter from

garbage and large dust particles.

Note:

– provide that the outlet air filter and the HEPA filter (18)

are always clean, because the overall performance of

the vacuum cleaner depends on it.

USING THE VACUUM CLEANER

Safety measures

• Do not use the vacuum cleaner near hot surfaces,

such as ashtrays and in places where inflammable

liquids are stored.

• Take sharp objects away from the floor before cleaning

to prevent unit damage.

• If the suction power of the vacuum cleaner decreases

rapidly while cleaning, switch it off immediately and

check the extension pipe (3) and the flexible hose (6)

for obstruction. Switch the vacuum cleaner off, then

unplug it, remove the obstruction and only after that

you can continue cleaning.

USING THE VACUUM CLEANER

ATTENTION! You may switch the vacuum cleaner on only

with the dust bin (7) and the HEPA filter (18) and the mesh

filter (19) installed in the dust bin, and with the outlet air

filter in the grid (16). Always make sure that the filters and

the mesh filter are installed properly.

• Before using the unit, unwind the power cord to the

required length and insert the power plug into the

mains socket.

• The yellow mark on the power cord indicates the maxi-

mum cord length. Do not unwind the power cord fur-

ther than the red mark.

• Press the on/off button (15) to switch the vacuum

cleaner on.

• During the operation you can control the suction power

using the manual suction power control (4) on the flex-

ible hose handle (5). After room cleaning switch the

vacuum cleaner off by pressing the on/off button (15)

and unplug the unit.

• To wind the power cord, press the button (12), hold

the winding cord with your hand to avoid its whipping

and damage.

• During the breaks you can place the brush (1) in the

horizontal brush storage (14).

Note: before replacing the brush (1) or the attach-

ments (20, 21) or cleaning the dust bin (7) switch the

vacuum cleaner off and take the power plug out of the

mains socket.

HEPA CLEANING SYSTEM

Cyclonic vacuum cleaner operates without dust bag.

Intake dirt is pushed into the dust bin (7) by force of the

air flow. The air is cleaned with the reusable washable

HEPA filter (18) inside the dust bin, and the outlet air foam

filter in the grid (16).

Attention!

Do not use the vacuum cleaner without the filter or if the

filter is damaged. The intake dust can get into the unit and

damage the motor.

Motor safety valve

The unit is equipped with the safety valve. If the dust bin

is full, the HEPA filter is blocked or the air vent is blocked,

the safety valve will switch on automatically to prevent the

motor overheating prolonging its service life.

CLEANING AND CARE

Cleaning the dust bin (7)

Easy to clean the dust bin from garbage and dust.

Easy to control the filling of transparent dust bin.

In order to avoid foreign smell from dust and garbage it is

recommended to remove the dust and garbage from the

dust bin (7) after every room cleaning.

– Switch the vacuum cleaner off and unplug it.

– Detach the flexible hose (6) from the dust bin (7) by

turning the flexible hose ending (8) counterclockwise.

– Holding the handle (11), press the release button (13)

and remove the dust bin (7) from the vacuum cleaner

body pulling upwards.

– Place the dust bin above the trash bin and press the

dust bin lid lock (17), the lid will open automatically

and you can remove the dust and garbage from the

dust bin (7).

– Close the dust bin lid and make sure that it is fixed

properly.

– Install the dust bin and the flexible hose back to their

places.

Cleaning the HEPA filter (18)

Regularly clean the HEPA filter (18) and the mesh filter

(19). It’s better to clean them while cleaning the dust bin.

– Remove the dust bin (7) from the vacuum cleaner body

as described in the previous chapter.

– Take the handle (11) and carefully turn the dust bin

counterclockwise, remove it from the filter block (10)

lid. Then remove the HEPA filter (18) from the filter

block (10) lid turning it counterclockwise.

– Remove the mesh filter (19) from the HEPA filter (18).

– Now wash the HEPA filter, the mesh filter and the dust

bin itself under a warm water jet and let them dry.

Attention!

– Wash the filter only with clean water, do not use soap

or detergent. It will damage the filter.

– Do not wash the filter in a dishwashing machine.

– Do not dry the HEPA filter with a hairdryer.

– Put the mesh filter (19) on the HEPA filter (18).

– Install the HEPA filter (18) back into the lid (10) and turn

it clockwise until clicking.

– Insert the lid (10) with the installed HEPA filter into the

dust bin (9) and turn it clockwise until it is fixed prop-

erly. There are corresponding marks on the lid, the dust

bin and the HEPA filter for proper installation.

Note: before installing the dust bin back into the vacuum

cleaner body, check the metal protection mesh of

the motor which is situated on the inlet opening of the

vacuum cleaner body under the dust bin. Foreign objects

in the protection mesh can significantly decrease the

suction power.

– Install the dust bin (7) into the vacuum cleaner body

until clicking.

ATTENTION!

Before installing the dust bin into the vacuum cleaner

body make sure that all filters are dry and there is no

moisture inside the dust bin.

Cleaning the outlet air filter

The outlet air filter cleans the air at the final stage before

releasing it from the vacuum cleaner. You can clean the

outlet filter in the following manner:

– Switch the vacuum cleaner off and unplug it.

– Remove the outlet filter grid (16) by pressing the clamp

on the side of the grid.

– Remove the air foam filter from the grid (16), wash it

under a lukewarm water jet and let it dry. Wash the filter

only with clean water, do not use soap or detergent. It

can damage the filter.

– Install the foam filter back into the grid (16) and install it

back to its place in the vacuum cleaner body.

Cleaning the vacuum cleaner body

– Wipe the vacuum cleaner body with a soft, slightly

damp cloth and then wipe it dry.

– Do not immerse the body of the vacuum cleaner, the

power cord and the power plug of the unit into water

or other liquids. Provide that no liquid gets inside the

vacuum cleaner body.

– Never use solvents or abrasives to clean the surface of

the vacuum cleaner.

STORAGE

• Before taking the vacuum cleaner away for long term

storage, clean its body, the dust bin (9) and the filters.

• For easy storing use the horizontal brush storage (14)

and the attachment holder (22).

• Keep the vacuum cleaner in a dry cool place out of

reach of children and disabled persons.

DELIVERY SET

Vacuum cleaner with the dust bin

and filters installed – 1 pc.

Flexible hose – 1 pc.

Extension pipe – 2 pc.

Universal brush with the “FLOOR/CARPET” switch – 1 pc.

Combined attachment – 1 pc.

Furniture brush attachment – 1 pc.

Attachment holder – 1 pc.

Manual – 1 pc.

TECHNICAL SPECIFICATIONS

Power supply: 220-240 V ~ 50-60 Hz

Rated input power: 1200 W

Maximum power: 1600 W

Suction power: 350 W

RECYCLING

For environment protection do not throw out the unit

and the batteries (if included), do not discard the unit

and the batteries with usual household waste after the

service life expiration; apply to specialized centers for

further recycling.

The waste generated during the disposal of the unit is

subject to mandatory collection and consequent disposal

in the prescribed manner.

For further information about recycling of this product

apply to a local municipal administration, a disposal

service or to the shop where you purchased this product.

The manufacturer preserves the right to change design,

structure and specifications not affecting general prin-

ciples of the unit operation without a preliminary noti-

fication due to which insignificant differences between

the manual and product may be observed. If the user

reveals such differences, please report them via e-mail

info@maxwell-products.ru for receipt of an updated

manual.

The unit operating life is 3 years

Guarantee

Details regarding guarantee conditions can be obtained

from the dealer from whom the appliance was purchased.

The bill of sale or receipt must be produced when making

any claim under the terms of this guarantee.

This product conforms to the EMC Directive

2014/30/EU and to the Low Voltage

Directive 2014/35/EU.

Пылесос

MW-3244

RUS

Дата производства изделия указана в серийном номере на табличке с техническими данными.

Серийный номер представляет собой одиннадцатизначное число, первые четыре цифры

которого обозначают дату производства. Например, серийный номер 0606ххххххх означает, что

изделие было произведено в июне (шестой месяц) 2006 года.

A production date of the item is indicated in the serial number on the technical data plate. A serial num-

ber is an eleven-unit number, with the first four figures indicating the production date. For example,

serial number 0606ххххххх means that the item was manufactured in June (the sixth month) 2006.

4 5

ENGLISH

ЗАПРЕЩЕНО УТИЛИЗИРОВАТЬ

С БЫТОВЫМ МУСОРОМ.

ОБРАТИТЕСЬ НА СООТВЕТСТВУЮЩИЙ ПУНКТ

ПЕРЕРАБОТКИ ЭЛЕКТРИЧЕСКОГО

И ЭЛЕКТРОННОГО ОБОРУДОВАНИЯ.

IM MW-3244_2-lang-A4.indd 2 10/5/20 11:41 AM

Maxwell MW-3244 [2/2] Пылесос mw 3244

Содержание

Похожие устройства
