Oursson JM4600/OR [11/28] Product certification
![Oursson JM4600/OR [11/28] Product certification](/views2/1860984/page11/bgb.png)
11
problem Solutions
A lot of pulp in
the juice
• With continued juicing and depending on the ingredients, juice may contain much pulp.
• To reduce the pulp in the juice, disassemble the juice cup and remove the pulp more often.
• If the lter or screw is damaged - it can aect the performance and quality of juice. It is recom-
mended to replace them. The service life of each part depends upon the duration and the
method of using the device, and pressing ingredients.
• If too much of the ingredients are loaded into the juice maker simultaneously, this can lead to
frequent stoppages and to a large number of pulp in the juice. Place ingredients slowly and in
small portions.
Extraneous
sounds when
the device is
working
• Make sure that all parts are correctly assembled.
• Do not turn the juice maker without ingredients or at least liquid in it. Empty working juice
maker may damage the pressure screw
• Depending on the type or size of various ingredients dierent noises my occur.
• Noise may occur when the juice maker is working on uneven or inclined surfaces. Lace it on a
at stable surface.
Pulp is very wet
• At the beginning of juicing, the pulp can be wet.
• The recovered pulp can be wet if you are using stale ingredients
Cup vibration • A small vibration of juice cup is allowed during operation. It is not considered a malfunction
The device has
stopped working
• Make sure the amount of fruit and vegetables is not too large and the motor is not overloaded.
• Make sure all the large seeds were removed from the fruit.
• Turn o the device and switch it on REV (Reverse) mode for 2-3 seconds. Turn on the device
again.
pRODUcT cERTIFIcATION
For information on product certication, see http://www.oursson.com or ask seller for a copy.
Specications
Model
JM4600 JM4700
Power consumption, W
max 150 max 150
Rated voltage
220-240 V~; 50-60 Hz 220-240 V~; 50-60 Hz
Protection class
I I
Storage and transportation temperature requirements*
-25 °C to +35 °C -25 °C to +35 °C
Operation temperature requirements
+5 °C to +35 °C +5 °C to +35 °C
Humidity requirements
15-75% 15-75%
Dimensions (H×W×L), mm
101x125x359 150х110х372
Weight, kg
1.6 2.2
*Products should be stored in dry, ventilated warehouses at temperatures below - 25°C.
Only a qualied specialist of an authorized service center OURSSON AG can repair the juice maker.
