EN20V Cordless Brushless Angle Grinder
TECHNICAL DATA
Type WX812 WX812.9 (812-designation of
machinery, representative of Angle Grinder)
WX812 WX812.9
Charger voltage 100-240V~ 50/60Hz
Rated voltage 20V Max**
No load speed 8500r/min
Disc bore 22.2mm
Disc size 125mm
Spindle thread M14
Wheel Grinding (Type 27)
Machine weight 2.2kg 1.6kg
**Voltage measured without workload. Initial
battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
ACCESSORIES
WX812 WX812.9
Spanner 1 1
Auxiliary handle 1 1
Wheel guard for grinding 1 1
Metal grinding disc 1 1
4.0Ah Battery pack (WA3553) 1 /
2.0A Charger (WA3880) 1 /
We recommend that you purchase your accessories listed
in the above list from the same store that sold you the tool.
Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.
OPERATING INSTRUCTIONS
Note: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for cutting, roughing and
brushing metal and stone materials without using
water.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the battery pack See Fig. A1
Charging the battery pack See Fig. A2
Installing the battery pack
WARNING: When
replacing the battery
pack, do not insert the
battery until the Grinding
Disc comes to a complete
stop!
See Fig. A3
ASSEMBLY
Assembling Auxiliary Handle See Fig. B
Assembling Grinding Disc
See Fig. C1,
C2, C3
Adjusting Wheel Guard
NOTE: Before any work on
the machine itself, remove
the battery pack. For work
with grinding discs, the
protection guard must be
mounted. Use the correct
type of disc for your
application.
The coded projection on the
wheel guard ensures that only a
guard that fits the machine type
can be mounted.
Open the clamping lever. Place
the wheel guard with coded
projection into the coded
groove on the spindle of the
machine head and rotate to
the required position (working
position).
To fasten the wheel guard, close
the clamping lever.
The closed side of the wheel
guard must always point to
the operator.
See Fig. D
OPERATION
Using On/Off Switch See Fig. E
Hand Grip Areas See Fig. F
