Intended use

This tool is intended for painting.

ASSEMBLY

1. Plug the spray gun into the compressor. Make sure the spray gun is fully inserted. (See

Fig. A1) After that, turn clockwise to adjust the spray gun to your desired position (See

Fig. A2) To disassemble, draw the spray gun out from the compressor.

2. Open the feeding cup cover and fill with paint. Then cover. (See Fig. B)

WARNING: Use paint specifically formulated for use with Air Brushes. DO

NOT use solvents that contain or emit harmful substances. DO NOT use

paints of high concentration, or the nozzle may be clogged. Recommended to

use water-soluble painting. Use colors which can be used with pressure value

14-18 PSI (0.10 -0.12 MPa)!

3. Connect the air brush and the hub. (See Fig. C)

WARNING: Before operation, make sure the speed control button on the

hub is at the“Min“ position. (See Fig. D)

OPERATION

1. Confirm the speed control button is set to “Min”. Grasp the tool by the grip. Press

the on/off switch on the hub. The dual function trigger regulates both paint volume and

air flow. Depress the trigger to start the air flow. Pull the trigger back to regulate paint

volume. Set maximum paint volume using the tail adjust screw. (See Fig. E)

NOTE: The speed is fixed, and can not be adjusted by the speed control button on the

hub.

2. Press the on/off switch on the hub to turn off after use.

WORKING HINTS

Before use, check the compressor and the spray gun to ensure they can work properly.

Please clean the feeding cup and spray gun instantly after use.

The nozzle may be clogged after long-term use. Please use the brush to clean.

Please carry out repairs or renovations under the guidance of after-sales staff.

MAINTENANCE

Remove the battery before carrying out any adjustment, servicing or mainte-

nance.

There are no user serviceable parts in your power tool. Never use water or chemical

cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power

tool in a dry place. Keep the motor ventilation slots clean. Keep all working controls free
