A26
Installing the Wall mount plate (Only for N1941W,N1941WP,N1941WE)
Wall mount plate(Separate purchase)
This is stand-type or wall mount type and is
connectable with Wall mount plate.
Please refer to the installation guide for more
details, which is provided when Wall mount plate
is purchased.LG recommends that wall mounting
be performed by a qualified professional
installer.
Kensington Security Slot
Connected to a locking cable that can be
purchased separately at most computer stores.
This monitor satisfies the specifications of the Wall mount
plate or the interchange device.
1
.
Place the monitor with its front facing downward on a soft cloth.
2. Separate the stand by pushing the PUSH button.
3.
Install the Wall mount plate.
Warning:
You can hurt your finger.
Good Position Bad Position
