Features
• Enhanced-IDE (ATAPI) interface.
• Power tray loading and ejection of disc. (The disc can also be
ejected manually.)
• Combination CD-R/RW and DVD-ROM Drive functions into one
drive.
• Supports Region playback control Phase II.
• Supports Windows 98, 2000, ME & XP/NT4.0.
• Supports Mt. Rainier.
• Supports DVD-RAM disc read.
• Automatic buffer underrun error prevention technology-
SuperLink
• 52X max Writing (CD-R), 32X max ReWriting (CD-RW), 16X
max Reading (DVD-ROM), and 52X max Reading (CD-ROM)*.
*Writing speed depends on capabilities of discs.
As a result, for ultra speed write/rewrite, you should use media
labelled Ultra Speed Write/ReWritable discs
Package Items
System Environment
Computer
This unit can be operated in the system environment explained here.
Specifications
350MHz (or faster) Pentium (for high speed,
500MHz or faster recommended)
64MB or greater(128MB or over recommended)
75MB or more free space.
(The free space needed for writing depends on
the quantity of data.)
Enhanced-IDE interface (as Primary Slave,
Secondary Master or Slave)
5.25-inch half-height bay required
+5V/+12V power socket required
Windows 98/2000/ME/XP or later*
CD-R : LG, Ricoh, Mitsubishi Kagaku Media,
Verbatim, Taiyo Yuden, Ritek, MBI, SKC
discs are recommended.
CD-RW :
Ricoh, Mitsubishi Kagaku Media,
Verbatim, Imation, Sony discs are
recommended.
System
requirements
Hard disk
Interface
Drive bay
Power
Software Required OS
CD-R, CD-RW discs
CPU
Memory
❋ The drive’s appearance and specifications may change without prior
notice.
Software
Install the appropriate CD Recording Authoring Software before using
this unit.
* Please uninstall any previous CD burning software you may have loaded
on your PC in order to prevent possible compatibility issues.
Once you have installed the application software, you may (if you wish) begin
to reinstall previous software, taking note for errors.
Worldwide support ; http://www.LGservice.com
Worldwide corporate site : http://www.LGE.com
Please visit www
.lgservice.com and install the program, “LG ODD Online
F/W update.” By using the program, you can automatically check the latest
information about FirmWares and update the FirmWare.
Items CD/DVD/CD-RW
General
Host Interface E-IDE/ATAPI
Supported Discs Read Function: CD-ROM, CD-ROM XA,
Audio CD, Mixed Mode (Audio and Data
Combined), CD-I FMV, Video CD, Photo CD (Single
and Multi -Session), CD-Plus/CD-Extra, CD-Text
DVD-Single/Dual, DVD-R/RW, DVD+R/RW,
DVD±R DL, DVD-RAM
Write Function: CD-ROM, CD-ROM XA, Audio CD,
CD-I FMV, Video CD, CD-Plus/CD-Extra
Disc Diameter 12cm/ 8cm, standard size CD's
(8cm disc can be used only with drive placed horizontally.)
Mounting direction
Horizontal/Vertical
Read/Write Speed
Write : (CD-R, max 52X): 8X, 16X, 24X, 32X, 40X, 48X, 52X
Write : (CD-RW, max 32X): 4X, 10X, 16X, 24X, 32X
Read : (CD-ROM): max 52X,
(DVD Single): max 16X
(DVD Dual): max 12X
Items CD/DVD/CD-RW
Performance
Data transfer rate
*Sustained
CD: R: 3000 to 7200 KB/s (20X-48X CAV)
RW: 2700 to 6000 KB/s (18X-40X CAV)
ROM: 3300 to 7800 KB/s (22X-52X CAV)
DVD: Dual: 7290 to 16200 KB/s (5.4X-12X CAV)
Single:
Data : 8700 to 21600 KB/s (6.5X-16X CAV)
Movie: 3370 to 8100 KB/s (2.5X-6X CAV)
-R/RW, +R/RW, +R/-R DL: 4450 to 10800KB/s
(3.3X-8X CAV)
DVD-RAM: 2700 to 6700KB/s (2.0X-5.0X)
*Burst(ATAPI) 16.67 MB/s (PIO Mode 4),
16.67 MB/s (Multi DMA Mode 2)
33.34 MB/s (Ultra DMA Mode 2)
Average Access CD-RW/CD-ROM: 100ms(Typical)
time(Random) DVD(Single Layer) : 120ms(Typical)
Buffer capacity 2 Mbytes (included 512KB programmed area)
MTBF
125000 Power On Hours (Duty Cycle 10%)
Audio Output level 0.72 Vrms +/- 10%
Environmental
Level
When operating Temperature: 5 °C to 45 °C
Humidity: 10% to 80% R.H.
When not operating Temperature: -40 °C to 60 °C
Humidity: 5% to 90% R.H.
Electrical
Power DC 5V, DC 12V
Item Quantity
- Internal CD Rewriter/DVD-ROM Drive 1
- CD Recording Software (with Power DVD) 1
- E-IDE (ATAPI) cable 1
- Mounting Screws 4
- Quick Set-up Guide for CD Rewriter/DVD-ROM Drive 1
Quick Set-up Guide
CD Rewriter/DVD-ROM Drive
GCC-H21N
To install of your product, please read this guide manual carefully and completely. For the detailed owner’s manual of the drive,
please refer to the CD manual.
P/NO. 3828HN1010H Ver. A
