3
VP83F
General Description
The Shure VP83F is a professional-quality condenser microphone designed for use with DSLR and video cameras. The VP83F features built-in flash
recording and captures crystal-clear, high definition audio, completely independent from other hardware. The intuitive menu makes configuration fast
and simple for use in almost any sonic environment.
① Windscreen
② Camera audio output
③ Camera shoe mount
④ Battery and memory card compartment
⑤ Rycote
®
integrated shockmount
⑥ Control panel
⑦ Headphone audio output
①
②
③
④
⑤
⑥
Features
⑦
Exceptional Audio Quality
• High-resolution recording (24 Bit/48khz sampling, WAV
format)
• Supercardioid/lobar pickup pattern rejects unwanted
sounds
• Interference tube for increased directionality
• RF Immunity
Built-in Flash Recording
• Records directly to microSD card (32 GB maximum)
• Intuitive menu for easy microphone configuration and
track management
• Separate outputs for headphone monitoring and camera
input with independent volume adjustment
Rugged and Reliable
• Durable, all-metal housing
• Rycote
®
integrated shockmount
• Shoemount adapter for easy installation
Accessories
• Rycote
®
foam windscreen
• 3.5 mm coiled audio cable
• (2) AA batteries (except in Argentina)
• Rycote
®
Windjammer™ (optional)
