Connection
Note: Before you start connection of external devices, ensure that power of the unit is switched off.
Following outputs are available in this unit:
Composite video
Use the cable with yellow plug of an AV cable to connect the composite video output of this unit to the video input of a
TV/monitor.
Component video
Use a 3-core AV cable to connect the component output of this unit to the corresponding input of your TV/monitor.
S-video
Use an S-video cable to connect the S-Video output of this unit to the S-Video input of your TV/monitor.
5.1CH audio
Use 3 pairs of audio cables to connect the 5.1 CH audio outputs of this unit to the 5.1 channel inputs of external audio
amplifiers or other players.
Stereo audio
Use a pair of AV cables (red for right/white for left) to connect the stereo audio outputs of this unit to the TV or a stereo
input of power amplifier.
Coaxial digital audio
Use a special coaxial cable to connect the coaxial output of this unit to the coaxial input of a power amplifier.
Optical digital audio
Use a special optical cable to connect the coaxial output of this unit to the optical input of a power amplifier.
MIC jack
MIC jacks are used to connect microphones (not included) to this unit.
Notes: The connection you should make depends on the TV/monitor input terminals. Don’t make all the connections at the
same time; otherwise the produced picture will be affected. The physical connection should accord to the audio output setup
of this unit.
