Audio setup

 SPEAKER SETUP: Downmix

LT/RT: The audio out is Left and Right channels format even if the original sound is

5.1CH format.

Stereo: The audio out format is stereo even if the original sound is 5.1CH format.

 SPDIF SETUP: Spdif output

SPDIF off: no digital signal out (optical or coaxial output off), only analog audio

output.

SPDIF/RAW: no decoding on the amplifier digital signal input.

SPDIF/PCM: the amplifier must be supported by PCM decoding or Dolby digital

decoding function.

 Karaoke setup

You can switch the microphone on or off, adjust the microphone threshold, microphone volume and echo.

Dolby setup

 DUAL MONO

Stereo: stereo output signal,

L-Mono: left output signal,

R-Mono: right output signal,

Mix-Mono: left and right output average signal.

 DYNAMIC

If watching large dynamic scope movie program at night, by selecting this mode you

can reduce the volume to a very low level and at the same time keep the fine details

sounds. In this case, this doesn’t disturb the family and keep the quality sound.

Video setup

 COMPONENT

S-Video: set to this item when connecting to S-Video terminals.

YUV: set video output in analog component video format when connecting to Y/U/V

terminals.

RGB: set video output in Red/Green/Blue format when connecting to SCART

terminals.

 TV MODE

You can choose between progressive (P-Scan) and interlaced output when playing

with “YUV” mode.

 SHARPNESS, BRIGHTNESS, CONTRAST
