Soundmax SM-2409 [15/38] System setup

System setup

1. Press SETUP button to enter the setup menu. In setup mode, press SETUP button again to quit the setup page.

2. Use LEFT/RIGHT cursor buttons to choose a setup page.

3. Press DOWN cursor button to enter the setup page selected.

4. U se UP/DOWN cursor buttons to select the option you want to adjust.

5. Press RIGHT cursor button to enter the adjustment list. Use UP/DOWN cursor buttons to select the adjustment and

press ENTER button to confirm and return to options list.

6. To return to setup page list press LEFT cursor button in the options list.

Note: Items in gray can't be set up. The setup is memorized and kept after power off.

System setup page

 Source: Disc, Card or USB.

 TV system: PAL or NTSC.

 Power resume: When this function is on, the unit can memorize the time

elapsed from the last time you played the disc. Then at the next playing, it will

resume playing from the memorized time.

 Video: S-Video.

 TV type

4:3/PS: When the unit is connected to the normal TV set, the wide-screen image is

shown on the full screen, but some part is cut off.

4:3/LB: When the unit is connected to the normal TV set, the wide-screen image is

shown and black bars appear on the top and bottom of screen.

16:9: Use this item when the unit is connected to the normal TV set, if you want to squeeze the picture.

 Password: Change the password. The initial factory password is 0000. You can set your own password. If you

forget your own password, you can use 0000 as general password.

 Parental: The control level is for parental to control playing content and protect your children from violence and

erotic. The disc, the level of which is higher than the setting level cannot be played.

 Default: Restore the initial factory settings.
