![Pedrollo PLURIJET 6/200 [3/4] Pos component construction characteristics](/views2/1874958/page3/bg3.png)
136
PLURIJET 90-130-200
5 6 9
7741
2 8
3
POS. COMPONENT CONSTRUCTION CHARACTERISTICS
1 PUMP BODY Stainless steel AISI 304 complete with threaded ports in compliance with ISO 228/1
2 BODY BACKPLATE Stainless steel AISI 304
3 IMPELLERS Stainless steel AISI 304
4 DIFFUSERS Stainless steel AISI 304
5 MOTOR SHAFT Stainless steel AISI 431
6 MECHANICAL SEAL
Seal Shaft Materials
Model Diameter Stationary ring Rotational ring Elastomer
FN-18 Ø 18 mm Graphite Ceramic NBR
7 BEARINGS 6304 2RS - C3 / 6204 ZZ - C3E
8 CAPACITOR
Pump Capacitance
Single-phase
(230 V or 240 V) (110 V )
PLURIJETm 5/90
PLURIJETm 3/130
PLURIJETm 3/200
31.5 μF - 450 VL 60 μF - 250 VL
PLURIJETm 6/90
PLURIJETm 4/130
PLURIJETm 4/200
45 μF - 450 VL 80 μF - 250 VL
PLURIJETm 5/130
PLURIJETm 5/200
50 μF - 450 VL
9 ELECTRIC MOTOR PLURIJETm:
single-phase 230 V - 50 Hz with thermal overload protector incorporated into the winding
.
PLURIJET: three-phase 230/400 V - 50 Hz.
➠ The three-phase pumps are fitted with high performance motors in class IE3 (IEC 60034-30-1)
– Insulation: class F
– Protection: IP X4
50 Hz | PLURIJET 90-130-200
