- 3 -

(EN)

INSTRUCTION MANUAL

WARNING: READ THE INSTRUCTION MANUAL CAREFULLY BEFORE

USING THE STARTER!

1. GENERAL SAFETY USER INSTRUCTIONS FOR THIS STARTER

In order to reduce the risk of personal injury and damage to

equipment, it is highly recommended to comply with all essential

safety measures and precautions when using the starter.

- Inexperience and untrained people should be properly

instructed before using the appliance.

- This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

- Children shall not play with the appliance.

- Cleaning and user maintenance shall not be made by children

without supervision.

Protect the eyes. Always wear protective goggles when

using acid lead accumulators.

- Avoid contact with battery acid. If an operator should be

sprayed or come into contact with the acid, rinse the

relative parts immediately under clean running water.

Continue to rinse the area until the physician arrives.

It is important to connect the cables with the poles in the

right direction:

First connect the red clamp to the positive terminal on the

vehicle battery (+ symbol).

Connect the black clamp to the vehicle chassis or the negative clamp

on the battery, at a distance from the fuel pipe.

- Use the starter in well ventilated areas. Do not attempt to use the

starter when there is gas or inammable liquids in the vicinity.

- Do not allow the black and red clamps to come into contact.

- USE IN EMERGENCY SITUATIONS ONLY: do not use the starter instead

of the vehicle battery. Use it during start-up operations only.

- Do not work alone. If there is an accident, the assistant can be of aid

to the operator.

Prevent electrical shocks. Be very cautious when applying

the clamps to non-insulated conductors or bus bars. Avoid

all body contact with surfaces of tubes, radiators, and

metal power substations whilst reading the vehicle battery voltage.

- Keep the work area clean at all times. Untidy cumbersome areas can

lead to injuries.

- Protect the starter appropriately from all possible damage. It must

only be used as indicated in this Instruction Manual.

- Ensure compliance with the indications in the work area. Do not use

in humid or wet facilities. Never leave it out in the rain. Always work

in well lit areas.

Always wear suitable clothing. Never wear baggy

clothing or jewellery that can get caught up in moving

parts. During all operations, the use of electrically

insulated protection clothing and non-slip boots must be worn

at all times. Persons with long hair must tie it back and wear a

hair net.

- Only experts are allowed to do repair work on the starter as it

involves signicant risk levels for inexperienced workers.

- Replacing parts and accessories. When performing maintenance

operations, replace with identical and original spare parts only. Use

of non-original spare parts invalidates all warranties.

- Make sure that the device is always positioned in a stable and well

supported manner.

Never climb over cables or electrical structures.

- Careful attention must be paid during maintaining work on the

starter. Check the condition of cables on a regular basis and if any

damage is detected, have the same repaired by an authorised and

qualied technician.

- Check there are no damaged parts. Before using this starter, carefully

check that all seemingly damaged parts and assess whether or

not they can operate correctly. Check that the cables are securely

fastened to the starter. Remember that only authorised and qualied

technicians are allowed to repair or replace damaged parts.

- Class A device:

This battery charger complies with the requirements of the technical

standard for products to be used in industrial environments and

for professional purposes. No compliance with the electromagnetic

compatibility in domestic use buildings is guaranteed and those

connected directly to a low voltage power supply network that

furnishes buildings designated to domestic use.

It is advisable to t the cables connecting to the μUSB, USB outlets

and to the Jack, with a noise lter, operating in the following range of

frequences: 1Mhz - 500Mhz with Z(10Mhz) about 1500 Ohm.

1.1 SPECIAL WARNINGS AND SAFETY PRECAUTIONS ON THE USE

OF THE LITHIUM BATTERIES INSIDE THE STARTER

Failure to observe the following rules can cause breakage, overheating,

bulging, re outbreak or explosion of the battery inside the starter:

- Never open the starter casing under any circumstances.

- Do not charge the battery in direct sunlight, near ames or in similar

conditions.

- Do not use the starter or position it in the vicinity of heaters, near

ames or in other hot areas.

- Only use the charger supplied with the device to charge the starter or

optional charger systems sold separately.

- Do not throw the starter into a re or heat it up.

- Do not invert the positive "+" and negative "-" connection polarities.

- Do not short-circuit the starter terminals.

- Do not perforate the starter casing with drill bits, do not hit it with a

hammer or stand on it.

- Do not position the starter inside stoves, microwave ovens etc.

- Do not throw the starter or cause high impacts.

- Do not modify or tamper with the starter casing.

- Refrain from using the starter if it emits strange smells, heats up or

deforms during use, charging or storage.

- Models with 12V voltage only:

Use is forbidden on vehicles with voltage other than 12V.

Use is forbidden for applications other than specied.

Keep this manual.

The manual should be read, paying attention to all the warnings and

safety precautions to be taken when using and maintaining the device,

the list of components and all technical specications.

Please keep this manual in a secure and dry place for future reference.

2. INTRODUCTION AND GENERAL DESCRIPTION

Intended use

Multi-functional, portable, battery-powered starter. Ideal for anyone

needing an emergency starter. Its applications include use on

motorcycles, engine-operated vehicles, boats and more besides.

Fully compatible with any 12-volt any 24-volt starter system (12V/24V

model only).

Test the battery status and the self-priming status (CCA) of the vehicle

battery; also test the load eciency of the vehicle alternator.

The starter uses LITHIUM BATTERIES; this makes the device

extremely compact and easy to handle.

The multifunctional starter is also equipped with a powerful, white led

light.

3. DESCRIPTION OF THE STARTER

3.1 STARTER AND MAIN COMPONENTS ASSEMBLY (Fig. A)

1. Multifunctional starter with starter cables and clamps.

2. Charging power adaptor.

3. Jack plug socket to charge the starter with a power adaptor as

standard.

4. White LED light.

5. Control panel.

6. Safety fuse compartment.

7. Side supports to hang the clamps in the rest position.
