Switching speeds / modes

Switching is carried out using the switch 3 (pic. 1). The switch has two positions, indicated by numbers «1» и «2».

Position "1" corresponds to a lower speed of rotation of the chuck; this mode is designed for screwing and

unscrewing screws and other works, requiring the application of signicant torque. In this position of the switch

tool develops maximum torque.

Position "2" corresponds to the increased speed of rotation of the chuck; this mode is designed to perform the

most ecient drilling. The maximum torque at this position of the switch is less than at the position "1".

In case, the switch 3 does not reach the end position, you need to bring it back, turn the machine on and o by

briey pressing the switch, perform a speed change after stopping the engine.

ATTENTION!

Do not switch speed until the spindle stops. Always send the switch 3 key to the end, do not

leave it in an intermediate position. Failure to follow instructions may cause damage to the

gearbox. .

Torque adjustment

Torque adjustment function allows you to choose the optimal eort of tightening screws, depending on their size

and working conditions. The choice of the optimal tightening force is carried out empirically.

Change of the torque is carried out by setting ring 2 to the position indicated by the arrow located at the top of

the case.

– positions 1… 19 serve for screwing in / out screws, however, a higher number corresponds to a higher torque;

– position

is for drilling, wherein torque limiting function is blocked.

NOTE. Numeric values indicated on the ring 2 (pic. 1) do not reect torque values expressed in Nm, and indicate

the ordinal position of the adjustment ring.

Light of the working area

LED light of working area turns on simultaneously with the engine when you press the switch key.

Replacement of tooling

ATTENTION!

Before changing the tooling, remove the battery from the tool or set the switch of the direction

of rotation to the middle position to prevent accidental activation of the tool and injury.

To open the chuck, turn the outer ring of its sleeve counterclockwise (when viewed from the front) until the tool

shank is positioned freely between the chuck jaws.

Install the tooling into the chuck. Use a tooling with a cylindrical or hex shank with a diameter of 0.8 to 10 mm

(from 2 to 13 mm for model CDL-18-02). Tooling with a shank less than 0.8 mm (less than 2 mm for model CDL-18-

02) cannot be properly centered in this chuck.

Clamp the chuck by turning its outer ring clockwise.

Make a trial tool enable, to make sure that the tooling is installed and centered.

NOISE AND VIBRATION

Noise and vibration characteristics are given in the table №1.

However, if the Electrical Rotary Hammer will be used for other work with the use of working tools, not provided

by the manufacturer, or maintenance will not meet the requirements, then the vibration level may be dierent.

ATTENTION!

Always use personal hearing protection.
