Руководство по эксплуатации станка JET IBG-10 14

11. ДЕТАЛИРОВКА

№ Деталь № Описание Размер Кол-во

1 ................ IBG8-04 ..................... Truss Head Screw ....................................................3/16”-24 x 3/8” .............. 9

2 ................ IBG10-03 ................... Base Plate ...................................................................................................... 1

6 ................ TS-0060051 ............... Hex Cap Screw ........................................................3/8”-16 x 1” ................... 4

7 ................ TS-0720091 ............... Lock Washer ............................................................3/8” ............................... 4

8 ................ IBG12-08 ................... Base ............................................................................................................... 1

9 ................ IBG12-09 ................... Cord Plate ...................................................................................................... 1

10 .............. IBG12-10 ................... Motor Housing ................................................................................................ 1

11 .............. IBG12-11RU .............. Stator ........................................................................380V, 50Hz, 3Ph .......... 1

12 .............. IBG12-12RU .............. Rotor............................................................................................................... 1

13 .............. IBG12-13 ................... Motor Fan ....................................................................................................... 1

14 .............. BB-6007ZZ ................ Ball Bearing ..............................................................6007ZZ ......................... 4

15 .............. IBG10-19 ................... End Bell .......................................................................................................... 2

16 .............. IBG8-26 ..................... Truss Head Screw ....................................................1/4”-20 x 3/4” ................ 8

17 .............. IBG12-17 ................... Wheel Guard .................................................................................................. 2

18 .............. TS-0680031 ............... Flat Washer ..............................................................5/16” ............................. 6

19 .............. TS-0051021 ............... Hex Cap Screw ........................................................5/16”-18 x 5/8” .............. 6

20 .............. IBG12-20 ................... Wheel Flange ...........................................................Ø1-1/4” hole.................. 2

21 .............. ................................... Grinding Wheel (option) ...................................................................................

22 .............. IBG10-24 ................... Wheel Flange ...........................................................Ø1” hole ........................ 2

23 .............. IBG8-24 ..................... Hex Nut (Left Hand Thread) .....................................5/8” ............................... 1

24 .............. IBG12-24 ................... Wheel Cover................................................................................................... 2

25 .............. IBG8-26 ..................... Truss Head Screw .................................................... 1/4”-20 x 3/4” .............. 10

26 .............. IBG12-26 ................... Tool Rest – Left .............................................................................................. 1

27 .............. TS-0680041 ............... Flat Washer ..............................................................3/8” ............................... 4

28 .............. TS-0060031 ............... Hex Cap Screw ........................................................3/8”-16 x 3/4” ................ 4

29 .............. IBG12-29 ................... Tool Rest – Right............................................................................................ 1

30 .............. TS-0060011 ............... Hex Cap Screw ........................................................3/8”-16 x 1/2” ................ 2

31 .............. IBG12-31 ................... Spark Guard – Left ......................................................................................... 1

32 .............. IBG12-32 ................... Eye Shield ...................................................................................................... 1

33 .............. IBG12-33 ................... Eye Shield Bracket – Left ............................................................................... 1

34 .............. IBG12-34 ................... Eye Shield Plate ............................................................................................. 1

35 .............. IBG8-36 ..................... Truss Head Screw ....................................................3/16”-24 x 1/2” .............. 1

36 .............. IBG8-37 ..................... Knob ............................................................................................................... 1

37 .............. TS-0680021 ............... Flat Washer .............................................................. 1/4” ............................... 1

38 .............. IBG12-38 ................... Spark Guard – Right....................................................................................... 1

39 .............. IBG12-39 ................... Eye Shield Bracket – Right............................................................................. 1

41 .............. ................................... Grinding Wheel (option) ...................................................................................

42 .............. IBG8-44 ..................... Hex Nut (Right Hand Thread) ...................................5/8” ............................... 1

43 .............. IBG10-43 ................... Dust Collect Hose Assembly .......................................................................... 1

44 .............. IBG12-44 ................... Truss Head Screw ....................................................M4 x 1/2”....................... 2

45 .............. IBG12-45RU .............. Magnetic Switch .......................................................KJD-18 400V, 50Hz ...... 1

46 .............. IBG12-46 ................... Truss Head Screw ....................................................1/4”-20 x 1/2” ................ 2

47 .............. IBG12-47 ................... Switch Bracket................................................................................................ 1

48 .............. IBG12-48T ................. Power Cord w/ P551 Plug ........................................H05VV-F 1.0mm² x 4G . 1

49 .............. IBG12-49 ................... Strain Relief .................................................................................................... 1

52 .............. IBG12-52 ................... Electrical Terminal .......................................................................................... 1

53 .............. TS-0680041 ............... Flat Washer ..............................................................3/8” ............................... 2

54 .............. IBG8-54 ..................... Dresser Assembly ....................................................Dia. 1-1/4 ...................... 1

54-1 ........... IBG8-54-1 .................. Body ............................................................................................................... 1

54-2 ........... IBG8-54-2 .................. Hood ............................................................................................................... 1

54-3 ........... IBG8-54-3 .................. Cutter.............................................................................................................. 4

54-4 ........... IBG8-54-4 .................. Cutter Washer ................................................................................................ 2

54-5 ........... IBG8-54-5 .................. Pin ............................................................................6mm.............................. 1

54-6 ........... TS-1503051 ............... Socket Head Cap Screw ..........................................M6 x 20 ......................... 1

54-7 ........... IBG8-54-7 .................. Square Nut ...............................................................M6................................. 1

55 .............. TS-0680041 ............... Flat Washer ..............................................................3/8” ............................... 2

56 .............. TS-0060011 ............... Hex Cap Screw ........................................................3/8”-16 x 1/2” ................ 2

57 .............. IBG12-32 ................... Eye Shield ...................................................................................................... 1

58 .............. IBG12-34 ................... Eye Shield Plate ............................................................................................. 1

59 .............. IBG8-36 ..................... Truss Head Screw ....................................................3/16”-24 x 1/2” .............. 1

60 .............. IBG8-37 ..................... Knob ............................................................................................................... 1

61 .............. TS-0680021 ............... Flat Washer .............................................................. 1/4” ............................... 1

100 ............ IBG12-100 ................. Eye Shield Assembly – Left (includes 30-37,53) ............................................ 1

101 ............ IBG12-101 ................. Eye Shield Assembly – Right (includes 38,39,55-61) ................................... 1
