2
ROTARY HAMMER
EN
PROPER USAGE AND GENERAL INFORMATION
Electrical Rotary Hammer is designed for hammer drilling in bricks, concrete and rocks, the destruction of brickwork,
punching strobes and grooves in concrete, stone, brick and also for drilling into dierent constructional materials.
The tool is designed for usage at an environment temperature from 0 °С to 40 °С, relative humidity not more than
80% and a lack of direct exposure of atmospheric condensation and excessive air dustiness.
Rotary Hammer is suitable only for private use and must be used in intermittent duty not more than 20 hours per
month. It is recommended to use on-loading not more than a nominal, for 10-15 minutes and then to have a break
for 20-30 minutes. This usage mode enables to complete domestic tasks eectively and prevents the tool from
a premature coming out of order.
This manual contains the information and the requirements necessary and sucient for a sure, eective and secure
use of the rotary hammer.
Due to constant improving of the tool the manufacture reserves the right to make minor changes in its construction,
not mentioned in this manual and not worsening its consumer and operational properties, eective and secure use.
COMPLETENESS OF SET
The set contains:
1. Electrical Rotary Hammer 1 pc.
2. Side handle 1 pc.
3. Depth gauge 1 pc.
4. Dust collector 1 pc.
5. Drill bit SDS+8x150 mm 1 pc.
6. Drill bit SDS+10x150 mm 1 pc.
7. Drill bit SDS+ 12x150 mm 1 pc.
8. Flat chisel SDS+14x250 mm 1 pc.
9. Point chisel SDS+ 14х250 mm 1 pc.
10. Container with grease 1 pc.
11. Set of spare carbon brushes 1 pc.
12. Instruction manual 1 pc.
13. Warranty card 1 pc.
14. Packing box 1 pc.
SPECIFICATIONS
Parameter Value
Maximum drilling diameter in concrete, mm 30
Maximum drilling diameter in wood, mm 40
Maximum drilling diameter in steel, mm 13
Impact energy, J 5
The number of operational modes 3+1
Safety clutch Yes
Type of chuck SDS-plus
Speed adjustment Yes
No load speed, min
-1
0-850
Impact rate, min
-1
0-4500
Power, W 1250
Rated voltage, V 230
Frequency, Hz 50
Cable length, m 3
Power indicator Yes
Indicator of carbon brushes runout Yes
Protection class IP20
Sound pressure level (LpA), dB 72
Vibration level (ah), м/с
2
3,5
Degree of protection against electric shock II
Weight net, kg
5,0
Weight gross, kg
6,7
