User manual
OPTICAL LEVEL
CONDTROL 24X/32X/ Spektra 32
User manual
OPTICAL LEVEL
CONDTROL 24X/32X/ Spektra 32
User manual
OPTICAL LEVEL
CONDTROL 24X/32X/ Spektra 32
User manual
OPTICAL LEVEL
CONDTROL 24X/32X/ Spektra 32
User manual
OPTICAL LEVEL
CONDTROL 24X/32X/ Spektra 32
User manual
OPTICAL LEVEL
CONDTROL 24X/32X/ Spektra 32
User manual
OPTICAL LEVEL
CONDTROL 24X/32X/ Spektra 32
DELIVERY PACKAGE
1. Opcallevel–1pc.
2. 2-mmhexwrench-1pc.
3. Adjusngpin-1pc.
4. Usermanual–1pc.
5. Hardcase–1pc.
OPERATION
1. Instrument set-up and leveling
a) Set desired height of the tripod
and place it on the ground. Use the
aachment screw to ghtly x the
opcallevelonthetripod(Figure2).
b) Rotate the liing screws A, B, C to
install the bubble vial in the center.
By rotang the A and B screws
simultaneously,movethebubbletothe
right.RotaonofthescrewCwillmove
thebubbleback(Figure3).
Congratulaonsonyourpurchaseofopcallevel24X/32X/Spektra32
CONDTROL.Safetyinstruconsprovidedinthisusermanualshouldbe
carefullyreadbeforeyouusetheproductfortherstme.
SAFETY REGULATIONS
Aenon!Thisusermanualisanessenalpartofthisproduct.Theuser
manualshouldbereadcarefullybeforeyouusetheproductfortherst
me. If the product is given to someone for temporary use, be sure to
encloseusermanualtoit.
-Donotmisusetheproduct.
- It is prohibited to disassemble or repair the product yourself. Entrust
productrepairtoqualiedpersonnelanduseoriginalsparepartsonly.
-Storetheproductbeyondreachofchildrenandunauthorizedpeople.
- Do not use the product in explosive environment,close to ammable
materials.
FUNCTIONS/APPLICATIONS
Opcallevels24X/32X/Spektra32CONDTROLareprofessionalmeasuring
instruments. They are equipped with a compensator with a magnec
dampingsystemwithworkingrange±15‘.Itallowstoquicklyandcorrectly
makehigh-precisionmeasurements.
CONDTROL opcal levels have 24X* and 32X** magnicaon telescope
withcoatedopcs,whichsignicantlyimprovesvisibilityandmakesaiming
toremoteobjectseasier.Theyhaveahorizontallimbwitha1°graduaon
marksandliingscrews,aswellasan opcal sight on thetelescopefor
convenienttargetsearch.
*-24Х
**-32Х и Spektra 32
ExTERNAL APPEARANCE
A
C
B A
C
B
2. Aiming and focusing
а)Grid:
Pointthetelescopeonabrightsurfaceorlevelingsta,usingthesight.
Rotatethe eyepieceunl youachieve a clear andbright image of the
grid.
в)Aiming:
Rotate the focusing screw forward to focus on the sta
standing at longer distance or back to focus on the sta
standingatcloserdistanceunlaclearimageappearson
the screen.Rotate the horizontaldrive screw to posion
theimageofthestaatthecenteroftheeldofview.
3. Measurements
а)Exceedence:
Aerpoinngonthestatakethereadingsofthemiddle
line,asshownonFigure4.(thereadingis1.195m).
в)Distance:
Take the readings of the upper and boom stadia lines.
Distancebetweentheinstrumentandthestawillbethe
following:
(Reading of the upper line – reading of the boom line) х100,
AsshownontheFigure4:
(1.352m-1.038m)х100=31.4m
с)Angle:
Point the vercal line of the grid to the
targetAandtaketheanglereadingαonthe
limb.PointtothetargetBandtaketheangle
readingβonthelimb.TheanglebetweenA
andBwillbe-α-β(Figure5).
ACCURACY CHECK AND ADJUSTMENT
Despite the fact that all optical levels with compensator are adjusted
atthefactory,itisnecessarytocarryoutaccuracycheckbeforeuse.
1. Checking the circular bubble vial
а) Adjust the lifting screws to center the bubble vial and rotate the
telescopeby180°.Thebubblevialshouldremaininthecenter(Figure6).
b) If the bubble vial is not in the center, it is necessary to perform
adjustment.
с)Rotatetheliftingscrewstomovethebubblevialhalfwaytothecenter
(Figure7).
d) Turn 2 adjusting screws to
adjustthepositionofthebubble
vial(Figure7).
e)RepeatstepsfromAtoDuntil
the bubble vial doesn’t deviate
fromthecenter(Figure8).
1
2
6
13
15
9
11
7
12
3
4
8
10
5
1
2
14
13
9
1.Objecvelens
2.Opcalpeepsight
3.Circularvialmirror
4.Eyepiececover
5.Adjusngscrewforsighngline
6.Eyepiece
7.Circularbubblevial
8.Horizontalcirclereferencemark
9.Horizontalcircle
10.Adjusngscrewsofcircularbubblevial
11.Liingscrews
12.Tripodmount5/8“(ontherearside)
13.Horizontaldrivescrews
14.Focusingscrew
15.Base
TECHNICAL SPECIFICATIONS
24x 32x Spektra 32
Standarddeviationfor1km
double
2 mm 1.5 mm 1.5 mm
Image Direct
Magnification 24x 32x 32x
Objectiveaperture 38mm 36mm
Minimalviewingdistance 0.6m
StadiaRatio 100
LevelvialSensitivity 8’/2mm
HorizontalCircleGraduation 1°
Typeofcompensator magnetic
Range 15’
SettingAccuracy 0.5”
Protectionrate IP54
Dimensions 190x128x123mm 210x130x145mm
Weight 1.2kg
Thread 5/8”
Figure2
Figure3
Figure4
A
B0
Figure5
Figure6
Center
Deviation of the bubble vial
Move the bubble vial to position
marked by dashed line
(half of deviation)
Figure7
Figure8
