![Dewalt D25324K [6/16] Heavy duty rotary hammerdrill d25313 d25223 d25323 d25324](/views2/1635767/page6/bg6.png)
ENGLISH
4
HEAVY-DUTY ROTARY HAMMERDRILL
D25313, D25223, D25323, D25324
Congratulations!
You have chosen a DEWALT tool. Years of experience, thorough product development and innovation make
DEWALT one of the most reliable partners for professional power tool users.
Technical Data
D25313 D25223 D25323 D25324
Voltage V 230 230 230 230
(U.K. & Ireland only) V 230/115 230/115 230/115 230/115
Type 2 2 1 1
Power input W 800 800 800 800
No-load speed min
-1
0–1,150 0–1,150 0–1,150 0–1,150
Load speed min
-1
0–830 0–830 0–830 0–830
Impact energy
Hammerdrilling J 0–3.1 3.1 0–3.1 0–3.1
Chiselling J 0–3.4 3.4 0–3.4 0–3.4
Maximum drilling range in
steel/wood/concrete mm 13 / 30 / 26 13/30/26 13/30/26 13/30/26
Chisel positions 51 52 51 51
Core drilling capacity in soft brick mm 65 65 65 65
Tool holder SDS Plus
®
SDS Plus
®
SDS Plus
®
SDS Plus
®
Collar diameter mm 54 54 54 54
Weight kg 3.0 3.3 3.4 3.5
L
PA
(sound pressure) dB(A)
85.4 88 85.4 85.4
K
PA
(sound pressure uncertainty) dB(A) 3.3
3.9
3.3
3.3
L
WA
(sound power) dB(A) 99.4
99
99.4
99.4
K
WA
(sound power uncertainty) dB(A) 3.3
3.9
3.3
3.3
Vibration total values (triax vector sum) determined according to EN 60745:
Drilling into metal
Vibration emissioni value a
h,D
=
m/s²
3.0 < 2.5 < 2.5 < 2.5
Uncertainty K = m/s²
1.6 1.5 1.5 1.5
Drilling into concrete
Vibration emissioni value a
h,HD
=
m/s²
18.0 9.6 10.5 10.5
Uncertainty K = m/s²
1.7 1.5 1.5 1.5
Chiselling
Vibration emissioni value a
h,Cheq
=
m/s²
18.0 6.4 10.5 10.5
Uncertainty K = m/s²
1.5 1.5 3.5 3.5
Screwdriving without impact
Vibration emission value a
h
=
m/s²
< 2.5 < 2.5 < 2.5 < 2.5
Uncertainty K = m/s²
1.5 1.5 1.5 1.5
Содержание
- Congratulations 6
- Heavy duty rotary hammerdrill d25313 d25223 d25323 d25324 6
- Technical data 6
- Defi nitions safety guidelines 7
- Ec declaration of conformity 7
- General power tool safety warnings 7
- Save all warnings and instructions for future reference 7
- Additional specifi c safety rules for rotary hammers 9
- Markings on tool 9
- Package contents 9
- Residual risks 9
- Description fi g 1 10
- Electrical safety 10
- Mains plug replacement u k ireland only 10
- Using an extension cable 10
- Accessories fig 3 11
- Assembly and adjustments 11
- Fitting the side handle fig 4 11
- Indexing the chisel position fi g 2 11
- Inserting and removing sds plu 11
- Selecting the operating mode fig 2 11
- Fitting a chuck adapter and chuck sold separately 12
- Forward reverse slider fig 6 12
- Instructions for use 12
- Operation 12
- Overload clutch 12
- Proper hand position fi g 1 7 12
- Replacing the dust cover fig 3 12
- Replacing the tool holder with the chuck fig 1 12
- Setting the drilling depth fig 5 12
- Switching on and off fig 1 12
- Chipping and chiselling fig 1 13
- Drilling with a core bit fig 1 13
- Hammerdrilling fig 1 13
- Maintenance 13
- Rotary drilling fig 1 13
- Screwdriving fig 1 13
- Cleaning 14
- Lubrication 14
- Motor brushes 14
- Optional accessories 14
- Protecting the environment 14
- Guarantee 15
- N079517 07 10 16
- Türkiye 16
- Ελλάς 16
