No. Code Qt. Description No. Code Qt. Description
1 C2330101 1 Body 135 GB/T 95 2 Washer φ12
2 C2110106 1 Front cover 136 C2330127 2 Horizontal locking cone
3 GB/T 70 3 Screw M6×15 137 GB/T 1337 1 Self-locking nut M8
4 GB/T 95 6 Washer φ6 138 C2330338 1 T-union 1/8"
5 GB/T 70 3 Screw M6×50 139 C2330360 1 Hose(Handle bar to locking cylinder)
6 GB/T 70 3 Screw M8×16 140 C2330360 1 Hose (tank to handle bar)
7 GB/T 95 4 Washer φ8 141 C2330342 2 Quick change adapter
8 C2110143 1 Left cover 142 C233012401 1 Locking handle bar
9 GB/T 70 6 Screw M6×15 143 GB/T 70 4 Screw M5×12
10 GB/T 95 6 Washer φ6 144 C2330313 1 Hose(Two locking cylinders link up )
11 C2110113 1 Rubber wheel support 145 JB 1092 2 O-ring φ70
12 C211010111 4 Rubber foot 146 GB/T 95 1 Washer φ12
13 C2110158 1 Bead liftng lever 147 C233016010 4 Tightener
14 GB/T 93 2 Spring washer φ8 148 C233016002 1 Cylinder rod
15 C2110159 1 box 149 GB/T 1337 8 Self-locking nut M8
16 C2110104 1 Spring 150 C211016001 1 Front flange
17 C2110108 1 Rubber support 151 JB/T 6997 1 V-seal
18 AR-2000 1 F.R.L.Combination 152 C2110106 1 Piston
153 GB/T 1337 1 Self-locking nut M12
101 C2330337 1 L-union 154 C2330105 1 Cylinder casing
102 C233011601 2 Locking cylinder piston φ48 155 C2110342 1 Union 1/8"
103 C233011603 2 C-seal 60 156 C2110103 1 Rear flange
104 GB/T 95 2 Washer φ6 157 C233016011 1 Bell-mouthed sheath
105 GB/T 70 4 Screw M6×40 158 C233016010 2 Rubber sheath
106 C233011602 2 Locking cylinder casing φ48 159 GB/T 5781 2 Screw M10×15
107 C2330117 1 Horizontal locking plate 160 C2330159 2 Washer φ10
108 GB/T 95 2 Washer φ6 161 GB/T 41 2 Nut M10
109 C2330133 2 Horizontal locking spring 162 GB/T 1337 1 Self-locking nut M12
110 C2330118 1 Arm protection support 163 GB/T 5781 2 Screw M10×15
111 GB/T 95 4 Washer φ8 164 GB/T 95 1 Washer φ10
112 GB/T 93 4 Spring washer φ8 165 GB/T 27 1 Hinged bolt
113 GB/T 70 1 Screw M8×20 166 C2330140 1 Tilting pin
114 GB/T 70 1 Screw M8×40 167 GB/T 5781 2 Screw M10×15
115 C2110132 1 Knob 168
C2330164 1 Plastic cover
116 C2330129 1 Plastic cover 169
C2330128 1 Plastic cover
117 C2110131 1 Spring 170 C233016007 1 Sheath support
118 C2330130 1 Vertical locking plate 171 C233016008 1 Rubber sheath
119 C2330126 1 Horizontal arm 172 C233016009 1 Rubber sheath
120 C2110125 1 Hexagonal vertical arm 173 C233016004 1 Cover
121 C2110124 1 Buffer bush 174 GB/T894 1 Seeger ring
122 C211012302 1 Pulley 175 C2330119 1 Complete tilting cylinder
123 C2110124 1 Munting head 176 C2330138 1 Vertical column
124 GB/T 119 1 Pin 177 C2330116 2 Complete Locking cylinder
125 GB/T 78 1 Screw M10×25
126 GB/T 95 1 Washer φ10 201 C2110122 1 Turntable φ610
127 GB/T 80 1 Screw M12×15 202 C2110145 4 Slide
128 C2330134 1 Shock absorber 203 C2110144 4 Jaw
129 GB/T 950 2 Screw M6×10 204 C2110120 1 Turntable washer
130 C2330131 2 Spacer φ6 205 GB/T 5781 1 Screw M16×20
131 C2110123 1 Complete mounting head 206 C2110163 1 Cap
132 GB/T 1337 1 Self-locking nut M8 207 C2110147 1 Control plate
133 GB/T 95 1 Washer φ8 208 C2110120 1 Washer
134 GB/T 1337 2 Self-locking nut M12 209 GB/T 894 1 Seeger ring φ65
10 SPARE PART LIST
-20-
