Wear gloves when handling saw blades
Do not expose the appliance to rain or high
humidity.
Disconnect the mains plug if the cord becomes
damaged or entangled.
Electrical safety
This tool is double insulated; therefore no earth wire
is required. Always check that the power supply cor-
responds to the voltage on the rating plate.
If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Stanley FatMax Service
Centre in order to avoid a hazard.
Voltage drops
Inrush currents cause short-time voltage drops. Under
unfavourable power supply conditions, other equipment may
be affected. If the system impedance of the power supply is
lower than 0.361, disturbances are unlikely to occur.
Using an extension cable
Always use an approved extension cable suitable for the
power input of this tool (see technical data). Before use,
inspect the extension cable for signs of damage, wear and
ageing. Replace the extension cable if damaged or defective.
When using a cable reel, always unwind the cable completely.
Use of an extension cable not suitable for the power input of
the tool or which is damaged or defective may result in a risk
of fi re and electric shock.
Features
This tool includes some or all of the following features.
1. Saw table
2. Blade guard
2a. Blade guard storage
3. Riving knife
4. Saw blade
4a. Saw blade storage
5. Rip fence
5a. Rip fence storage
6. Mitre gauge
6a. Mitre gauge storage
7. Dust bag
8. On/off switch
9. Leg stand
10. Bevel adjustment locking knob
11. Blade elevation handle
12. Leg stand locking knob
13. Blade tilting wheel
14. Locking handle for extension table
15. Locking handle for rip fence
16. Extension table
17. Spanner wrench X2
18. Guide rail
19. Push stick
20. Table insert
21. Overloaded protector
22. Leg stand level adjustor
23. Power cable
24. Power cable storage tabs
Assembly
Open the box and lift the saw out.
Place the saw on a smooth, fl at surface such as
a workbench or strong table.
Assembling the leg stand (Fig. A, B & C)
Note:
The leg stands have been designed so they can only
be assembled one way. ensure that the legs always slope
outwards as shown on front cover and assembly drawing on
page 2.
Unscrew and remove all four leg stand locking knobs (12)
as shown in fi gure A.
Place the table saw upside down on a stable surface,
and insert the leg stands (9) as shown in fi gure B. Ensure
correct orientation.
Replace the leg stand locking knobs (12) ensuring they
pass through the holes on the leg stands (9) and tighten
securely, as shown in fi gure B.
The table saw comes with a leg stand level adjustor (22),
this can be adjusted to compensate for irregular fl oors, as
shown in fi gure C.
Riving knife set-up (Fig. D, E & F)
Warning!
For transport reasons, the riving knife (3) has been
fi xed in the lower position before initial commissioning. Only
work with the machine if the riving knife (3) is in the upper
position. Fitting the riving knife (3) in the upper position is as
follows:
Remove the securing screw (20a) on the table insert (20)
and lift the table insert clear from the saw, as shown in
fi gure D.
Raise the saw blade and riving knife assembly by turning
the blade elevation handle (11) anti clockwise, as shown
in fi gure E.
Loosen the locking handle (3a) and pull the riving knife (3)
into the upper position, as shown in fi gure F.
Return the locking handle (3a) to the locked position.
Blade guard assembly (Fig. G)
The blade guard (2) is supplied with a pre-assembled bolt
(2a) fi xed into the correct position.
