Sinbo SJ-3139 [10/44] Attention before using

-9 -

ATTENTION BEFORE USING

1. This machine is set with safety unit, when the handle does not fasten

the cover or the cutter seat is not fastened, the motor cannot turn, so as to ensure safety

for the user.

2. When disassembling or assembling the juicer, press the upper of feed port of the cover

with your hand, then force the handle to slide in or out of cover slot.

3. When disassembling juicing net, first remove the cover and residue barrel, then turn

the middle ring up to 30 degrees by holding juicing nozzle with your hand, and take up,

the juicing net will automatically leave the rotor.

4. In order to avoid damage, before using, first check power supply for compliance with

rated voltage .

5. Clean all parts able to disassemble (refer to the section of "maintenance and cleaning").

6. When assembling, please carefully read the diagram of "name and position of main

components".

7. Please carefully read the "attentions" before using.

JUICING

1. Before using, please confirm the button switch of the main machine in stop state, in

this way, in case assembly is not completed, starting the main machine can be avoided,

so unnecessary damage for persons or property avoided.

2. Before juicing, first confirm juicing net and rotor clutched in position, and no hard

contact between juicing net cutter and transparent cover. Put the transparent cover on,

put the handle into the cover slot, then turn on the machine.

3. Before using, please make sure to put the juice mouth to drip position and after turning

off the machine, put the juice mouth to anti-drip position to avoid juice come out without

juice cup and make the table dirty.

4. For using, assemble according to the diagram of "name and position of main

components". Turn on power supply, press switch to let the machine run no-load for 5

sec. Put prepared vegetable or fruit into feed port of the juicer, press with the pushing

bar, evenly, hard and slowly, juice of the vegetable or fruit can be found, original, fresh,

good for health.

5. Note: When pressing food with the pushing bar, force shall be even or indirect, pressing

force shall not be more than 1 kg, no too sudden force, otherwise, juicing effect will be

reduced.

OPERATING TIME

This machine is designed with button switches of O grading, I grading, II grading (O for

stop, I for weak grading, II for strong grading). For juicing, select strong grading, for

operating time, after operating for 1min, stop for 1min, then use again. After the above

operation is performed for three times, stop for 15 min, do not operate until the motor

is cooled, in this way, service life of this machine will be prolonged, the machine will

serve you more efficiently.
