7
ENGLISH
(Original instructions)
• Open the chuck by turning the front part
with one hand while holding the rear part
with the other.
• Insert the bit shank into the chuck.
• Firmly tighten the chuck by turning the
front part with one hand while holding
the rear part with the other.
Removing and refitting the chuck (fig. C)
• Open the chuck as far as possible.
• Remove the chuck retaining screw by
turning it clockwise using a screwdriver.
• Tighten an Allen key into the chuck and
strike it with a hammer.
• Remove the Allen key.
• Remove the chuck by turning it
counterclockwise.
• To refit the chuck, screw it onto the
spindle and secure it with the chuck
retaining screw.
Use
Warning! Let the tool work at its own pace.
Do not overload.
Charging the battery (fig. D)
The battery needs to be charged before first
use and whenever it fails to produce
sucient power on jobs that were easily
done before. When charging the battery for
the first time, or after prolonged storage, it
will only accept an 80% charge. After
several charge and discharge cycles, the
battery will attain full capacity. The battery
may become warm while charging; this is
normal and does not indicate a problem.
Warning! Do not charge the battery at
ambient temperatures below 4°C or above
40°C. Recommended charging temperature:
approx. 24°C.
• To charge the battery (5), remove it from
the tool and insert it into the charging
base (8). The battery will only fi t into the
charging base in one way. Do not force.
Be sure that the battery is fully seated in
the charging base.
Plug in the charger (fig. E)
After normal use, a charging time of 3 hours
will provide sucient power for most
applications. However, further charging for
up to 3-5 hours could significantly increase
the use time, depending on the battery and
charging conditions.
Remove the battery from the charger.
Warning! Do not use the tool while it is
connected to the charger.
Selecting the direction of rotation
• A forward/reverse control button
determines the direction of the tool and
also serves as a lock o button (Fig. A).
• To select forward rotation, release the
trigger switch and depress the
forward/reverse control button.
• To select reverse, depress the
forward/reverse control button the
opposite direction. The center position of
the control button locks the tool in the o
position. When changing the position of
the control button, be sure the trigger is
released.
Torque Settings (fig. F)
• To set the tool’s torque, rotate the
adjustable torquecollar clockwise as
required.
• The positions are marked around the collar
and the higher the number, the higher the
torque.
• Each click in a clockwise direction means
an increase in the torque produced.
Position 17 is the drill mode and is marked
with the picture of a drill bit. In this
position the clutch will not operate. This
permits heavy duty drilling / driving
screws.
Switching on and o
• To switch the tool on, press the trigger
switch (3). The tool speed depends on
how far you press the switch.
• To switch the tool off, release the trigger
switch.
