14 | English
1 609 92A 4JX | (01.10.2018) Bosch Power Tools
Reciprocating saw AdvancedRecip 18
Tool holder SDS
Stroke mm 23
Max. cutting depth
– in wood mm 100
– in steel (unalloyed) mm 20
– Pipe diameter mm 20
Weight according to
EPTA-Procedure 01:2014
kg 2.1
Weight with 2.5 Ah battery
(PBA18 2,5Ah) according
to EPTA-Procedure
01:2014
kg 2.5
Permitted ambient temperature
– during charging °C 0 to +45
– during operation
A)
and
during storage
°C −20 to +50
Recommended batteries PBA 18V...V -.
PBA 18V...W-.
Recommended chargers AL 22.. CV
AL 18.. CV
A) Limited performance at temperatures <0°C
Noise/vibration information
Noise emission values determined according to
EN 62841-2-11.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 86dB(A); sound power level
97
dB(A). Uncertainty K=5dB.
Wear hearing protection
Total vibration values a
h
(triax vector sum) and uncertainty K
determined according to EN62841-2-11:
Cutting boards with saw blade S3456XF:
a
h,B
=10m/s
2
, K=1.5m/s
2
;
Cutting wooden beams with saw blade S3456XF:
a
h,WB
=10.5m/s
2
, K=1.5m/s
2
.
The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure detailed in EN 62841
and may be used to com-pare power tools. They may also be
used for a preliminary estimation of vibration and noise
emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.
Fitting
u Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage. There is risk of injury
from unintentionally pressing the on/off switch.
Charging the battery (see figureB)
u Use only the chargers listed in the technical data. Only
these chargers are matched to the lithium-ion battery of
your power tool.
Note: The battery is supplied partially charged. To ensure
full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery
is discharged, the power tool is switched off by means of a
protective circuit: The application tool no longer rotates.
u Do not continue to press the On/Off switch after the
power tool has automatically switched off. The battery
can be damaged.
To remove the battery (8), press the release button (10)
and pull the battery back and out of the power tool. Do not
use force to do this.
Battery charge-control indicator
When the on/off switch (6) is pressed in halfway or com-
pletely, the battery charge indicator (5) indicates the bat-
tery's state of charge for several seconds. The indicator con-
sists of three green LEDs.
LED Capacity
Continuous light 3 x green > 66%
Continuous light 2 x green 33–66%
Continuous light 1 x green 11–33%
Slowly flashing light 1 x green <11%
The 3 LEDs in the battery charge indicator (5) flash quickly if
the temperature of the battery is above the permitted oper-
ating temperature range.
Inserting/changing the saw blade
u When fitting or changing the saw blade, wear protect-
ive gloves. Blades are sharp and can become hot when
used for prolonged periods of time.
u While replacing the saw blade, ensure that the saw
blade receptacle is free of material residue, e.g. wood
or metal chips.
