13
EN
LED light indicator (9)
Before operation, the LED light will be activated
when the On/Off switch is slightly pressed, and
will automatically turn off 20 seconds after the
On/Off switch is released.
The tool and battery are equipped with a
protection system. When the LED Light is quickly
flashing 3 seconds and turn off, the system will
automatically cut off power to the tool to extend
battery life. The tool will automatically stop
during operation if the tool and/or battery are
placed under one of the following conditions:
• Overloaded: The tool is operated in a manner
that causes it to draw an abnormally high
current. In this situation, release the Trigger
Switch on the tool and stop the application that
caused the tool to become overloaded. Then pull
the Trigger Switch again to restart.
• Overheated: Under the condition above, if
the tool does not start, the Tool and Battery are
overheated. In this situation, let the Tool and
Battery cool before pulling the Trigger Switch
again.
• Low battery voltage: The remaining Battery
capacity is too low and the tool will not operate.
In this situation, remove and recharge the
Battery.
WARNING: To turn on the light, press the
On/Off switch and make sure the Forward/
Reverse Rotation Control is on right/left position.
See Fig. E
PROBLEM SOLUTION
1. WHY DOES THE DRILL NOT TURN ON WHEN YOU
PRESS THE SWITCH?
The forward/reverse rotation control, which is on top of the
trigger, is positioned in the lock function. Unlock the forward/
reverse rotation control by putting it into the required rotation
position. Push the trigger and the drill will start to rotate.
2. THE DRILL STOPS BEFORE THE SCREW IS COM-
PLETELY TIGHTENED. WHY?
Verify the torque position of the torque adjusting ring,
you can find the torque-adjusting ring between the
chuck and the drill body. Position 1 is the lowest torque
(screw driving force) and position 20 is the highest
torque (screw driving force). Position is for drill opera-
tion. Regulate the torque adjusting ring to a higher
position to reach the best result.
3. REASONS FOR DIFFERENT BATTERY PACK WORK-
ING TIMES
Charging time problems, as above, and having not used
a battery pack for a prolonged time will reduce the battery
pack working time. This can be corrected after several
charge and discharge operations by charging & working
with your drill. Heavy working conditions such as large
screws into hard wood will use up the battery pack
energy faster than lighter working conditions. Do not re-
charge your battery pack below 0oC and above 45oC as
this will affect performance.
