10
Adjusting the depth of cut using the scale (g. I)
u Fit the router bit as described above.
u Loosen the locking screw (28).
u Pull the plunge lock lever (4) up.
u Plunge the router down until the router bit touches the
workpiece.
u Push the plunge lock lever (4) down.
u Move the pointer (29) in the zero position on the scale (10).
u Add the desired depth of cut to the starting position.
u Move the depth stop bar (9) to the calculated position on
the scale.
u Tighten the locking screw (28).
u Fine adjust using the adjusting knob (30).
u Pull the plunge lock lever (4) up and let the router return to
its original position.
u After switching the router on, plunge it down and make the
desired cut.
Adjusting the depth of cut using a piece of wood (g. J)
u Fit the router bit and plunge the router down as described
above.
u Pull the depth stop bar (9) up.
u Place a piece of wood with a thickness equal to the
desired depth of cut between the depth stop (27) and the
depth stop bar (9).
u Tighten the locking screw (28).
u Fine adjust using the adjusting knob (30).
u Remove the piece of wood.
u Pull the plunge lock lever (4) up and let the router return to
its original position.
u After switching the router on, plunge it down and make the
desired cut.
Adjusting the revolver depth stop (g. K)
After turning the revolver depth stop to the desired setting, you
can ne-adjust the depth stop to be used. If you want to make
several cuts with a different depth of cut, adjust each of the
depth stops.
u Turn the depth stop screw (31) up or down as required
using a screwdriver.
Setting the speed
u Set the speed control knob (3) to the required speed.
Use a high speed for small diameter router bits. Use a low
speed for large diameter router bits.
Using a batten as a guide (g. L)
When it is not possible to use the edge guide, for example
when routing grooves in the back panel of a bookcase to
support shelves, proceed as follows:
u Select a piece of wood with a straight edge to use as
a batten.
u Place the batten onto the workpiece.
u Move the batten until it is in the correct position to guide
the tool.
u Securely clamp the batten to the workpiece.
Using the template guide (g. D)
The template guide can be used to make a cutout shape from
a template, for instance a letter.
u Secure the template over the workpiece with double-sided
tape or ‘G' clamps.
u The router bit must extend below the ange of the
template guide, to cut the workpiece in the shape of the
template.
Using the distance piece (g. E)
The distance piece can be used for trimming wooden or
laminate vertical projections.
Using the centring pin (g. F)
The centring pin can be used to cut out circular patterns.
u Drill a hole for the point of the centring pin in the centre of
the circle to be cut.
u Place the router on the workpiece with the point of the
centring pin in the drilled hole.
u Adjust the radius of the circle with the bars of the edge guide.
u The router can now be moved over the workpiece to cut
out the circle.
Using the copy follower (g. G)
The copy follower helps to maintain an equal cutting distance
along the edge of irregularly shaped workpieces.
u Place the router on the workpiece at the desired distance
from the edge to be copied.
u Adjust the bars of the edge guide until the wheel is in
contact with the workpiece.
Switching on and off
Switching on
u Keep the lock-off button (2) depressed and press the on/
off switch (1).
u Release the lock-off button.
Switching off
u Release the on/off switch.
Warning! Always operate the tool with both hands.
Hints for optimum use
u When working on outside edges, move the tool
counterclockwise (g. M). When working on inside edges,
move the tool clockwise.
u Use HSS router bits for softwood.
