Kress BL KU124 [10/20] Voltage measured without workload initial battery voltage reaches maximum of 20 volts nominal voltage is 18 volts

TECHNICAL DATA

TYPE DESIGNATION KU124 (1 - DESIGNATION

OF MACHINERY, REPRESENTATIVE OF DRILL)

KU124

Rated voltage

20V Max**

No load speed

0-600/0-2000/min

Number of clutch positions

18+1

Max torque

65 N.m

Chuck capacity

13 mm

Max. drilling

capacity

Steel 13mm

Wood 40mm

Machine weight

2.0 kg

Battery capacity 4.0Ah

** Voltage measured without workload. Initial

battery voltage reaches maximum of 20 volts.

Nominal voltage is 18 volts.

ACCESSORIES

KU124

6A Charger (KCH2007) 1

4.0Ah Battery pack (KPB2004) 2

Double ended bits (PH2/SL5.5) 1

Hook 1

Bit Clip 1

We recommend that you purchase your accessories

listed in the above list from the same store that sold

you the tool. Refer to the accessory packaging for

further details. Store personnel can assist you and offer

advice.

OPERATING

INSTRUCTIONS

NOTE: Before using the tool, read the

instruction book carefully.

Assembly and Operation

ACTION FIGURE

BEFORE OPERATION

Checking the battery charge

condition

See Fig. A1

Removing the battery pack See Fig. A2

Charging the battery See Fig. A3

Installing the battery pack See Fig. A4

ASSEMBLY

CHUCK ADJUSTMENT.

Warning: Always lock

off trigger switch and

disconnect tool from power

source when changing

accessories. Always ensure the

bit is secure before starting the

tool. Damage to the Chuck or

a loose bit may cause possible

personal injury.

Removing the bits See Fig. B1

Inserting the bits See Fig. B2

Assembling the belt hook and

bit clip

See Fig. C1,

C2,C3, C4

OPERATION

Forward/reverse rotation control

Warning: Never change

the direction of rotation

when the chuck is rotating,

wait until it has stopped!

See Fig. D1,

D2,D3

TWO-SPEED GEAR CONTROL

See Fig. E

TORQUE ADJUSTMENT

DRILLING

SCREWDRIVING

See Fig. F

Operating the on/off switch

WARNING! Do not

operate for long

periods at low speed

because excess heat will be

produced internally.

See Fig. G
