10
Edge router
Technical data OFK 700 EQ
Wattage 720 W
Speed (idling) 10,000 – 26,000 rpm
Cutter shank Ø 8 mm
Inclination angle of the router table 1.5°
Weight 2.0 kg
Safety level / II
The specifi ed illustrations can be found at the be-
ginning of the operating instructions.
Symbols
Warning of general danger
Wear ear protection!
Read the Operating Instructions/Notes!
1 Use for intended purpose
The OFK 700 EQ is intended for fl ush trimming and
profi ling of wood, plastic and similar materials.
The user is liable for damage and injury
resulting from incorrect usage!
2 Safety instructions
2.1 Rules
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fi re and/
or serious injury.
Save all warnings and instructions for future
reference.
The term „power tool“ in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
2.2 Tool-specifi c safety rules
- Only operate machine with a guide table and
extractor hood fi tted in accordance with regula-
tions.
- Only use milling tools that are EN 847 certifi ed for
rotating speeds of at least 26,000 rpm. Tools that
are cracked or misshapen must not be used.
- Ensure that the milling tool is fi rmly seated and
check that it runs smoothly.
- Only use original Festool accessories.
Wear suitable protection such as
ear protection, safety goggles, a
dust mask for work which gener-
ates dust, and protective gloves
when working with raw materials
and when changing tools.
3 Noise and vibration information
Typical values established in compliance with EN
60745:
Sound-pressure level 80 dB(A)
Sound-power level 91 dB(A)
Measuring uncertainty allowance K = 3 dB
Wear ear protectors!
Overall vibration levels (vector sum for three direc-
tions) measured in accordance with EN 60745:
Vibration emission level (3-axis)
Machine housing a
h
= 6 m/s²
Auxiliary handle a
h
= 4 m/s²
Uncertainty K = 2 m/s²
The emission values specifi ed (vibration, noise)
were measured in accordance with the test con-
ditions stipulated in EN 60745 and are intended
for machine comparisons. They are also used for
making preliminary estimates regarding vibration
and noise loads during operation.
The emission values specifi ed refer to the main
applications for which the power tool is used. If the
electric power tool is used for other applications,
with other tools or is not maintained suffi ciently
prior to operation, however, the vibration and noise
load may be higher when the tool is used. Take into
account any machine idling times and downtimes to
estimate these values more accurately for a speci-
fi ed time period. This may signifi cantly reduce the
load during the machine operating period.
4 Electrical connection and operation
The mains voltage must correspond with the volt-
age on the rating plate!
See Fig. 1 for connection and disconnection of the
power cable.
Always switch the machine off before con-
necting or disconnecting the mains lead!
The switch (2.1) acts as an ON/OFF switch (I = ON
/ 0 = OFF).
