Huawei C3020-10-I-P (3.6mm) [2/5] Technical specifications

Huawei C3020-10-I-P (3.6mm) [2/5] Technical specifications
Model C3020-10-I-P(3.6mm)
Major Specifications
Main control
CPU Hi3516D V300
Computing power 1 TOPS
Memory DDR3 0.2500 GB
Flash type SPI NAND Flash 256.0 MB
Max capacity
MicroSD card slot that supports microSDHC/microSDXC; maximum
memory card capacity: 256 GB
Camera
Image sensor 1/2.7" CMOS 2MP 1920(H)*1080(V)
Focal length 3.6mm
Max f-number F1.6
Lens aperture type Fixed iris
Angle of view Horizontal: 91.09°; vertical: 48.18°
IR range 30m
Intelligence
Face/Body
Face Face detection
Person Person detection
Other intelligences
Behavior analysis Fast movement,Tripwire crossing,Intrusion,Area entry or exit,Loitering
Crowd flow analysis Queue length,Head counting,Crowd flow statistics
Audio anomaly Sudden volume increase or decrease
Heat map Supported
Scene change Supported
Defocus Supported
Open ecosystem
Data openness Data openness
SDK (proprietary protocol),REST API (proprietary protocol),GA/T
1400,GB/T 28181
Codec
Video encoding format MJPEG/H.264/H.265
Video encoding channels Triple streams
Video frame rate Configurable (25 fps or 30 fps)
Intelligent encoding Extra265/264
Image ISP
Min illumination
Color: 0.002 lux (F1.6, AGC ON); B/W: 0.001 lux (F1.6, AGC ON) or 0
lux (infrared illuminator enabled)
Day/Night mode Auto (ICR), color, or B/W
White balance Auto/Manual/OnePush
Digital noise reduction 2D/3D noise reduction
WDR 120 dB
Technical Specifications
