VTS VENTUS PRO PVS PO 30 AC [2/16] Read this document carefully before attempting to start up the device
![VTS VENTUS PRO PVS 21x21 [2/16] Read this document carefully before attempting to start up the device](/views2/1893541/page2/bg2.png)
VTS reserves the right to implement changes without prior notice.
www.vtsgroup.com Page 2 of 16 ver. 2.0 (11.2021)
1. Introduction
This document describes functionality of CO2 concentration transducer based on
integrated MH-Z19B sensor, equipped with RS-485 interface using MODBUS RTU
protocol and 0-5V / 0-10V analogue output.
NOTES:
1) Read this document carefully before attempting to start up the device!
2) The device must be installed by qualified staff only.
1.1. Functions of the device
▪ CO2 measurement
▪ 0-5V or 0-10V analogue output (hardware selectable range) proportional to
CO2 concentration
▪ 3 status LEDs
▪ RS485 serial interface for remote management (setup and reading of
measurement values)
◦ MODBUS RTU protocol
◦ integrated terminating resistor 120Ω
◦ communication in HALF DUPLEX mode
◦ hardware/software configurable address in the range 1-247
◦ hardware configurable communication baud rate: 19200, 9600, 4800,
2400
◦ software configurable communication baud rate: 115200, 57600,
38400, 19200, 9600, 4800, 2400
1.2. Device characteristics
The main function of the CO2 transmitter is to measure the CO2 concentration in
the air using an integrated MH-Z19B sensor. The measurement result, as well as the
sensor missing/error status, is processed by the built-in microprocessor and then
made available on the RS-485 bus via registers of the MODBUS RTU protocol.
Additionally, the measurement result is available as analog signal on the 0-5V / 0-
10V voltage output.
