VTS VENTUS PRO PVS PO 120 AC [24/25] Notebook
![VTS VENTUS PRO PVS PO 120 AC [24/25] Notebook](/views2/1893542/page24/bg18.png)
MODEL
7-12°C 90-70°C
AIR
FLOW
(m³/h)
WATER
INLET-
OUTLET
(inc)
WATER
INLET-
OUTLET
(inc)
DRAIN
(inc)
ABSOLUTE
MOTOR
POWER
(Watt)
MAX.
CURRENT
(A)
2 Pipe
Weight
(Kg)
4 Pipe
Weight
(Kg)
DIMENSION
CAPACITY
(kW)
CAPACITY
(kW)
A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
FVS-DL-21 2,1 6,3 350 3/4"-3/4" 1/2"-1/2" 3/4" 54 Watt 0,28 A 14,1 15,9 480 530 642 672 505
FVS-DL-23 2,3 6,9 400 3/4"-3/4" 1/2"-1/2" 3/4" 56 Watt 0,28 A 14,1 15,9 480 530 642 672 505
FVS-DL-26 2,6 8 485 3/4"-3/4" 1/2"-1/2" 3/4" 57 Watt 0,35 A 14,7 16,5 480 530 642 672 505
FVS-DL-29 2,9 8,7 490 3/4"-3/4" 1/2"-1/2" 3/4" 63 Watt 0,35 A 15,1 17 480 530 642 672 505
FVS-DL-37 3,7 11,2 670 3/4"-3/4" 1/2"-1/2" 3/4" 66 Watt 0,35 A 20,7 23,3 830 880 992 1022 855
FVS-DL-42 4,1 12,5 780 3/4"-3/4" 1/2"-1/2" 3/4" 70 Watt 0,35 A 20,7 23,3 830 880 992 1022 855
FVS-DL-49 4,9 14,7 900 3/4"-3/4" 1/2"-1/2" 3/4" 86 Watt 0,5 A 21,1 23,8 830 880 992 1022 855
FVS-DL-51 5,1 15,4 960 3/4"-3/4" 1/2"-1/2" 3/4" 90 Watt 0,5 A 21,1 23,8 830 880 992 1022 855
FVS-DL-58 5,8 16,9 940 3/4"-3/4" 1/2"-1/2" 3/4" 92 Watt 0,5 A 21,9 24,8 910 960 1072 1102 935
FVS-DL-65 6,5 19,2 1170 3/4"-3/4" 1/2"-1/2" 3/4" 123 Watt 0,63 A 32,8 36,5 1310 1360 1472 1502 1335
FVS-DL-76 7,6 22,6 1470 3/4"-3/4" 1/2"-1/2" 3/4" 128 Watt 0,85 A 33,8 37,5 1310 1360 1472 1502 1335
FVS-DL-89 8,9 26,5 1570 3/4"-3/4" 1/2"-1/2" 3/4" 132 Watt 0,7 A 39,4 43,2 1660 1710 1822 1852 1685
FVS-DL-102 10,2 30,7 1920 3/4"-3/4" 1/2"-1/2" 3/4" 170 Watt 1,00 A 40,2 44 1660 1710 1822 1852 1685
FVS-42 YB 6,75 20,59 1360 1"-1" - 3/4" 1 X 150 Watt 1 x 1.6 A 28 - 510 560 672 702 535
FVS-52 YB 9,42 33,4 2450 1"-1" - 3/4" 2 X 150 Watt 2 x 1.6 A 40 - 710 760 872 902 735
FVS-62 YB 12,2 38,97 2670 1"-1" - 3/4" 2 X 150 Watt 2 x 1.6 A 44 - 910 960 1072 1102 935
FVS-72 YB 14,32 42,79 2768 1"-1" - 3/4" 2 X 150 Watt 2 x 1.6 A 48 - 1110 1160 1272 1302 1135
FVS-82 YB 19,61 58,28 3930 1"-1" - 3/4" 3 x 150 Watt 3 x 1.6 A 52 - 1310 1360 1472 1502 1335
FVS-44 YB 6,6 8,74 1310 1"-1" 1/2"-1/2" 3/4" 1 x 150 Watt 1 x 1.6 A - 29 510 560 672 702 535
FVS-54 YB 8,99 13,27 2262 1"-1" 1/2"-1/2" 3/4" 2 X 150 Watt 2 x 1.6 A - 41 710 760 872 902 735
FVS-64 YB 11,76 16,06 2510 1"-1" 1/2"-1/2" 3/4" 2 X 150 Watt 2 x 1.6 A - 45 910 960 1072 1102 935
FVS-74 YB 14 18,38 2670 1"-1" 1/2"-1/2" 3/4" 2 X 150 Watt 2 x 1.6 A - 50 1110 1160 1272 1302 1135
FVS-84 YB 19,12 24,33 3765 1"-1" 1/2"-1/2" 3/4" 3 x 150 Watt 3 x 1.6 A - 54 1310 1360 1472 1502 1335
All values in the capacity table are calculated according to the High Fan speed.
TECHNICIAL SPECIFICATIONS
FVS- DL- 21 - 102 FVS - 42...82 YB - FVS 44...84 YB
Notebook
49
FVS - FANCOIL UNITS
48
