The specifi ed illustrations can be found at the
beginning of the operating instructions.
1 Introduction
Thank you very much for purchasing the Domino
Dowel Jointer DF 500 Q from Festool.
Please observe the information in these Operat-
ing Instructions and the enclosed documents.
They are for your own safety and to help prevent
damage to the machine.
2 Technical data
Power 420 W
Speed (no load) 25 500 rpm
Jointing depth, max. 28 mm
Jointing width, max. 23 mm + jointer bit
diameter
Jointing bit diameter, max. 10 mm
Connecting thread of drive shaft M6 x 0.75
Weight (excluding cable) 3.2 kg
Degree of protection
/ II
3 Pictograms
Note, Danger!
Wear ear protection!
Manual, read the instructions.
Wear a protective mask!
4 Intended use
The Domino dowel jointer is designed to produce
Domino dowelled joints in soft and hard wood, chip
board, plywood and fi bre boards. All applications
beyond this are regarded as unspecifi ed use.
The Domino dowel jointer is designed and ap-
proved for use by trained persons or specialists.
The user is liable for damage and injury
resulting from incorrect usage!
5 Safety instructions
5.1 General Safety Rules
WARNING! Read all safety warnings and
all instructions.
Failure to follow the warnings and instruc-
tions may result in electric shock, fi re and/or
serious injury.
Save all warnings and instructions for future
reference.
The term „power tool“ in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
5.2 Tool-specifi c safety rules
- Hold power tool by insulated gripping surfaces,
because the cutter may contact its own cord.
Cutting a ”live” wire may make exposed metal
parts of the power tool “”live”” and could give
the operator an electric shock.
- The tools must be designed for the speed
specifi ed on the power tool at a minimum. Tools
running at overspeeds can fl y apart and cause
injury.
- Use the machine only with the guide frame
mounted. The guide frame protects the user
against broken-off parts of the jointer bit and
accidental contact with the jointer bit.
- The DF 500 Q must only be fi tted with the jointer
bits offered by Festool for this purpose. The
use of other jointer bits is prohibited due to the
increased risk of injury.
- Never work with blunt or damaged jointer bits.
Blunt or damaged jointer bits can lead to a loss
of control of the power tool.
- When the motor unit is released, it must move
back actuated by spring force so that the jointer
bit disappears completely in the protective
cover. If this does not happen, the machine must
be switched off immediately and repaired before
reuse.
To protect your health, wear a P2 protec-
tive mask.
Dowel jointer
Table of contents
1 Introduction ...............................................12
2 Technical data .......................................... 12
3 Pictograms ................................................12
4 Intended use .............................................12
5 Safety instructions ....................................12
6 Control elements ......................................13
7 Power supply and start-up .......................13
8 Machine settings .......................................13
9 Working with the machine ........................14
10 Maintenance and care ...............................15
11 Accessories, tools .....................................15
12 Disposal ....................................................15
13 Warranty ...................................................15
14 EC-Declaration of Conformity ..................16
15 Example applications ................................ 16
16 Fault correction .........................................17
