5.3 Noise and vibration information
The typical values determined in accordance with
EN 60745 are:
Sound-pressure level 84 dB(A)
Sound-power level 95 dB(A)
Measuring uncertainty allowance K = 3 dB
Wear ear protection!
Vibration emission value a
h
(vector sum for three
directions) and uncertainty K measured in accord-
ance with EN 60745:
Vibration emission value a
h
= 3,0 m/s²
K = 1,5 m/s²
The emission values specifi ed (vibration, noise)
were measured in accordance with the test con-
ditions stipulated in EN 60745 and are intended
for machine comparisons. They are also used for
making preliminary estimates regarding vibration
and noise loads during operation. The emission
values specifi ed refer to the main applications for
which the power tool is used. If the electric power
tool is used for other applications, with other tools
or is not maintained suffi ciently prior to opera-
tion, however, the vibration and noise load may be
higher when the tool is used. Take into account any
machine idling times and downtimes to estimate
these values more accurately for a specifi ed time
period. This may signifi cantly reduce the load dur-
ing the machine operating period.
6 Control elements
(1.1) ON/OFF switch
(1.2) Rotary switch for Domino dowel-hole
width
(1.3) Unlocking device for motor unit / guide
frame
(1.4) Auxiliary handle
(1.5) Clamping lever for angle guide
(1.6) Selection slide for material thickness
(1.7) Notch lever for Domino dowel-hole depth
(1.8) Notch lever lock
(2.1) Spindle lock
(2.2) Extraction nozzle
(2.3) Clamping lever for jointing height adjust-
ment
(2.4) Stop latch
7 Power supply and start-up
The mains voltage must correspond to
the specifi cation on the rating plate.
Always switch the machine off before
connecting or disconnecting the mains
lead!
See Fig. 2 for connection and disconnection of the
power cable.
To switch on, push the switch (1.1) forwards until
it engages. Pressing the back end of the switch is
suffi cient to release the switch-on lock and switch
the machine off.
8 Machine settings
Always remove the power supply plug
from the socket before carrying out any
work on the machine.
8.1 Changing tools
Required tools: fork wrench a/f 8 (supplied).
Always wear protective gloves during tool change
due to the risk of injury from the sharp tool cut-
ters.
a) Removing the tool
- Lift the unlocking lever (4.2) until it audibly en-
gages with the fork wrench (4.1).
- Separate the motor unit (4.5) and the guide
frame (4.4).
- Press and hold in the spindle lock (5.1).
- Release and unscrew the jointer bit (5.2) with
the fork wrench.
- Release the spindle lock.
b) Inserting the tool
- Before inserting a new jointer bit, ensure that
the machine, the guide frame and the guides
(4.3) are clean. Remove any contamination that
may be present. Only use sharp, undamaged
and clean tools.
- Press and hold in the spindle lock (5.1).
- Use the fork wrench to screw on the jointer bit
(5.2).
- Release the spindle lock.
- Slide the guide frame onto the motor unit until
it audibly engages.
8.2 Adjusting the milling depth
- Open the notch lever lock (1.8) by pressing it.
- Use the locking lever (1.7) to set the desired
jointing depth (12 mm, 15 mm, 20 mm, 25 mm,
28 mm). For the jointer bit with a diameter of 5
mm, only jointing depths of 12 mm, 15 mm and
20 mm are permitted due to its short shank
length.
- Release the notch lever lock again.
A special cutter is available for the DOMINO
dowel 4x20 mm (due to risk of breakage). Note
the following when using this cutter (D 4-NL 11
HW-DF 500):
- Set the routing depth to 20 mm using the stop
lever (1.7). The actual routing depth is 10 mm.
