USING THE UNIT AS AN UPRIGHT

• Unwind the power cord and plug into the 230V~ outlet.

• Insert the extension tube into the hand vac.

• Choose the appropriate accessory (crevice tool or floor brush) and attach it to suction hole opening

on the hand vacuum.

Note: You may choose not to attach the crevice tool or floor brush when operating as an upright.

• Press the “1” position on the On/Off power switch turn the unit on. When finished using the unit, press

the “0” position on the On/Off power switch to turn the unit off.

• When finished using the unit, wind the power cord around the cord winding hooks for easy storage.

Using the Unit as a Hand Vacuum

• Disconnect the extension tube from the hand vac by releasing the handle port from the locking clip

and removing the extension tube from the hand vac handle. Once the extension tube is removed, snap

the handle port shut.

Note: You may choose to leave the crevice tool or floor brush attached to the hand vac when operating

as such.

• Press the “1” position on the On/Off power switch to turn the unit on. When finished using the unit,

press the “0” position on the On/Off power switch to turn the unit off.

CLEANING & CHANGING THE DUST CUP FILTER

Changing and Cleaning the Dust Cup Filter

In order to achieve the best performance, empty the dust cup container and clean the dust cup filter

after each use.

1. To remove the dust cup container, press down on the dust cup container release button (Fig. 8) and

separate the dust cup container from the main unit. (Fig. 9)

Press down on the dust

cup container release

button

Fig. 8

Fig. 9

Separate the dust cup

container from the main

body.

2. Pull out the dust cup filter. (Fig. 10)

Fig.10

Dust cup container

Dust cup filter

3. Empty the dust from the dust cup container.

4. Rinse the dust cup filter in cold water, and then let it air dry for 24 hours before replacing it back in

the dust cup container.
