2
VTS reserves the right to introduce changes without prior notice
OMM_HE_SEC_ver 1.7
2 Scope of application
The maximum power of electric heaters available for given sizes and types of AHUs is shown below. A full list of the available powers will be
provided in Chapter 3 - Technical Details.
Modular AHU - VVS
Size - VVS
21
30
40
55
75
100
120
150
180
230
400
500
650
Maximum slices number
pcs
2
3
3
3
3
3
3
3
3
3
3
3
3
Single slice power
kW
18
18
24
30
30
36
36
36
36
36
36
36
36
Total heater power
kW
36
54
72
90
90
108
108
108
108
108
108
108
108
Table 1 – maximum available power for AHU VVS
Compact Standing AHU – VVSc
Size - VVSc
21
30
40
55
75
100
120
150
Maximum slices number
pcs
2
3
3
3
3
3
3
3
Single slice power
kW
18
18
24
30
30
36
36
36
Total heater power
kW
36
54
72
90
90
108
108
108
Table 2 – maximum available power for AHU VVSc
Compact Suspended AHU - VVSs
Size - VVSs
5
10
15
20
30
Maximum slices number
pcs
1
1
2
2
2
Single slice power
kW
10
12
18
18
18
Total heater power
kW
10
12
36
36
36
Table 3 – maximum available power for AHU VVSs
NVS AHU
Size - NVS
23
39
65
80
Maximum slices number
pcs
1
2
3
3
Single slice power
kW
18
18
18
24
Total heater power
kW
18
36
54
72
Table 4 – maximum available power for AHU NVS
3 Technical details
The current version of electric heaters is delivered in two power variants - low power, adjusted to AHUs with relatively low heating demand, and
high power, for AHU cases for facilities with higher thermal requirements. These types differ mainly in the types of electrical connections of the
individual heaters in the assembly (star connection for low power or delta connection for high power).
Appropriate connection between the heaters is made at the heater production stage - the installer only needs to connect the power and control
cables - it is not allowed to modify the heater system connections in relation to the factory configuration.
